795CFKV2 CIRCULATING FAN KIT 795C
INSTALLATION and OPERATING INSTRUCTIONS
Valor models 700, 780 and 785 Series Heaters
Note: This kit must be installed or serviced by a qualifi ed installer, service agency or gas supplier.
These instructions are to be used in conjunction with the main installation instructions for the above
listed models.
WARNING: If these instructions are not followed exactly, a fi re or explosion may result
causing property damage, personal injury or loss of life.
GROUNDING: This power supply must be installed and grounded in accordance with local codes,
or in the absence of local codes, with the current Canadian Electrical Code CSA C22.1. or in the
USA the National Electrical Code ANSI/NFPA70 latest edition.
Description of System
The models listed above have been designed to
accommodate the installation of an air circulation fan.
Operated via the remote control handset and having
variable speed control, the fan is designed to boost the
natural convection through the heater; this may be a
desirable feature dependent on the fi replace location
and room layout.
It is preferable to install the circulating fan before
the heater is installed although it may also be
retrofi tted at a later date provided power is available
at the fan location. However, please note that the
retrofi tting of the fan is done by disconnecting the gas
and removing the heater form the cavity.
The fan is designed for automatic operation to come
on and off when the burner comes on and off. The
fan speed can be controlled from the remote control
handset. There are four speeds available. The fan,
if turned on, will start approximately 4 minutes after
lighting the appliance and will continue to run for
approximately 10 minutes after the burner is shut off.
The fan will go on and off at the speed last selected by
the user.
4004226-01
© 2013, Miles Industries Ltd. All rights reserved.
G3.5
CSA approved for use only with
G4
&
Operation
To operate the fan, press the "SET" button on the
remote handset until only the fan icon (
on the display and is fl ashing. Press the up/down
buttons to set the fan speed (
means the fan is OFF. Once the fl ashing stops, the fan
is set. The fan icon and number of bars will show when
the remote is in other modes to confi rm the fan status.
Note: The fan, when plugged in, provides power for
the remote control receiver via the fan control module.
Therefore batteries are no longer required in the
receiver other than for back-up purposes. A battery
is still required in the remote control handset.
Electrical Requirements
The fan kit requires a power supply of 120 Volts,
1 phase, 60 Hz. Full load current is less than 1 amp.
) appears
). No bar showing
