Approved for use with Valor heater model 530 only
WARNING
!
A barrier designed to reduce the risk of burns from the hot viewing
glass is provided with this appliance and shall be installed
for the protection of children and other at-risk individuals.
Note: This kit must be installed or serviced by a qualifi ed
installer, service agency or gas supplier. These instructions
are to be used in conjunction with the main installation
instructions for the above listed heater model.
WARNING: If the information in these instructions is not
followed exactly, a fi re or explosion may result causing
property damage, personal injury or loss of life.
FOR INSTALLATION WITH A VALOR 530 ENGINE READ THE
FOR 530 ENGINE CONFIGURATIONS AND VENTING, REFER TO MAIN
INSTALLATION BOOKLET SUPPLIED WITH THE ENGINE.
4001165-06
©2013, Miles Industries Ltd.
P
ORTRAIT
Bolero Cast Front
541BPC
Installation and Owner's Manual
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
FOLLOWING INSTRUCTIONS.
I NSTALL ER
Leave this manual
with the appliance.
CO N SU MER
Retain this manual
for future reference.
