Daewoo DSL-15M1TC Service Manual page 43

IO_2
173 C_2
(RD18)
IO_3
172 C_3
(RD19)
IO_4
171 C_4
(RD20)
IO_5
169 C_5
(RD21)
IO_6
168 C_6
(RD22)
IO_7
167 C_7
(RD23)
177 IO_17 (DQM2)
IO_8
166 YUVCLK
(DQM3)
IO_9
165 Y_0
(RD24)
IO_10
164 Y_1
(RD25)
IO_11
163 Y_2
(RD26)
IO_12
162 Y_3
(RD27)
IO_13
161 Y_4
(RD28)
IO_14
159 Y_5
(RD29)
IO_15
158 Y_6
(RD30)
IO_16
157 Y_7
(RD31)
155 RA4
154 RA5
153 RA6
152 RA7
151 RA8
150 RA9
149 RA11
147 CKE
146 RCLK
144 RA3
143 RA2
141 RA1
140 RA0
Input 1) Digital Video output C bit 2
Non-pull 2) GPIO
Input 1) Digital Video output C bit 3
Non-pull 2) GPIO
Input 1) Digital Video output C bit 4
Non-pull 2) GPIO
Input 1) Digital Video output C bit 5
Non-pull 2) GPIO
Input 1) Digital Video output C bit 6
Non-pull 2) GPIO
Input 1) Digital Video output C bit 7
Non-pull 2) GPIO
Input
GPIO
Non-pull
Input 1) Digital Video output Clock
Non-pull 2) GPIO
1) Digital Video output Y bit 0
Input
2) GPIO
Non-pull
1) Digital Video output Y bit 1
Input
2) GPIO
Non-pull
1) Digital Video output Y bit 2
Input
2) GPIO
Non-pull
1) Digital Video output Y bit 3
Input
2) GPIO
Non-pull
1) Digital Video output Y bit 4
Input
2) GPIO
Non-pull
1) Digital Video output Y bit 5
Input
2) GPIO
Non-pull
1) Digital Video output Y bit 6
Input
2) GPIO
Non-pull
1) Digital Video output Y bit 7
Input
2) GPIO
Non-pull
Input
DRAM address 4
Input
DRAM address 5
Input
DRAM address 6
Input
DRAM address 7
Input DRAM address 8
Input
DRAM address 9
Input
DRAM address bit 11
Pull-Down
output DRAM clock enable
Input Dram clock
Input
DRAM address 3
Input
DRAM address 2
Input
DRAM address 1
Input
DRAM address 0
42
