Daewoo DSL-15M1TC Service Manual page 41

216 SPDIF
217 APLLVDD3
218 APLLCAP
219 APLLVSS
220 ADACVSS2
221 ADACVSS1
222 ARF GPIO
223 ARS GPIO
224 AR GPIO
225 AVCM
226 AL GPIO
227 ALS GPIO
228 ALF GPIO
229 ADACVDD1
230 ADACVDD2
196 DACVDDC
195 VREF
194 FS
193 YUV0 CIN
192 DACVSSC
191 YUV1 Y
190 DACVDDB
189 YUV2 C
188 DACVSSB
187 YUV3 CVBS
Output
2~16MA,
SPDIF output
SR : ON/OFF
Non-pull
Power 3.3V Power pin for audio clock circuitry
Analog Input APLL External Capacitance connection
Ground Ground pin for audio clock circuitry
Ground Ground pin for AUDIO DAC circuitry
Ground Ground pin for AUDIO DAC circuitry
1) AUDIO DAC Sub-woofer channel output While internal
Output
2) AUDIO DAC not used: GPIO
1) AUDIO DAC Right Surround channel output
2) While internal AUDIO DAC not used:
Output
a. SDATA3
b. GPIO
1) AUDIO DAC Right channel output
2) While internal AUDIO DAC not used:
Output
a. SDATA1
b. GPIO
Analog AUDIO DAC reference voltage
1) AUDIO DAC Left Surround channel output
2) While internal AUDIO DAC not used:
Output
a. SDATA2
b. GPIO
1) AUDIO DAC Left Surround channel output
2) While internal AUDIO DAC not used:
Output
a. SDATA0
b. GPIO
1) AUDIO DAC Center channel output
Output
2) While internal AUDIO DAC not used:GPIO
Power 3.3V power pin for AUDIO DAC circuitry
Power 3.3V power pin for AUDIO DAC circuitry
Video Interface ( 18 )
Power 3.3V power pin for VIDEO DAC circuitry
Analog Bandgap reference voltage
Analog Full scale adjustment
Output 4MA, 1) Video data output bit 0
SR 2) Compensation capacitor
Ground Ground pin for VIDEO DAC circuitry
Output 4MA, 1) Video data output bit 1
SR 2) Analog Y output
Power 3.3V power pin for VIDEO DAC circuitry
Output 4MA, 1) Video data output bit 2
SR 2) Analog chroma output
Ground Ground pin for VIDEO DAC circuitry
Output 4MA, 1) Video data output bit 3
SR 2) Analog composite output
