"Output" Button Toggle Sign
Number of Pixels Configured
Control Status
Control Mode (DMX, Art-Net, sACN,
CRMX, Bluetooth, WiFi)
Power Button: Light On: Press and hold for 1 second. Light Off: Press and hold for 2 seconds. Double Tap: Go to Status Screen.
Output Button: Toggle the button to enable/disable light output for manual mode operation. Change the color/intensity
without the change affecting the environment.
Link Button: On CRMX: For RX, press and hold to unlink light. For TX, Single tap to send pairing signal.
Double Tap to bring up Wireless Menu (Pg 13.)
Left / Minus Button: Decrease a value or navigate Left.
Right / Plus Button: Increase a value or navigate Right.
Enter / Save Button: Enter selection, Save Value.
Upgrade Port: USB-C Port for performing software updates with a USB-C Thumb Drive.
Key Interface
Profile and Number of Channels
Output Mode
Control Address
