Summary of Contents for Quasar Science Crossfade X

  • Page 1 ENGLISH Crossfade X LED Linear Light...
  • Page 2: Table Of Contents

    Crossfade X Table of Contents Copyright ..............................3 Safety Information .
  • Page 3: Copyright

    Crossfade X Copyright Copyright © 2022 All rights reserved. Original Instructions: English All rights reserved throughout the world. No part of this publication may be stored in a retrieval system, transmitted, copied or reproduced in any way, including, but not limited to, photocopy, photograph, magnetic or other record without the prior agreement and permission in writing of Videndum Plc.
  • Page 4: Safety Information

    Crossfade X Safety Information Important information on the safe installation and operation of this product. Read this information before operating the product. For your personal safety, read these instructions. Do not operate the product if you do not understand how to use it safely. Save these instructions for future reference.
  • Page 5 Crossfade X Operation WARNING Special precautions and handling instructions are contained in this user guide and should be strictly adhered to for safe and reliable operation. WARNING Never use flammable or combustible materials and solvents around lights. CAUTION The product should not be used outside the operating temperature limits. Refer to the product technical specifi ations for the operating limits for the product.
  • Page 6: Overview

    Crossfade X Overview WHAT’S IN THE BOX Description 2', 4' or 8' Crossfade X Light Q-Boot Shock Absorbers AC Power Cord...
  • Page 7: Crossfade X - Overview

    Lens Hatch Slim Diffuser Control Side Heat Sink *Crossfade X - 2' (921-2302) shown as reference TECHNICAL SPECIFICATIONS Physical Length, Width Height Q15W2060XG, Q25W2060XG, Q50W2060XG, Q75W2060XG, and Q100W2060XG: Width & height = 1.5” 3.81 cm Q15W2060XG: 1’ / 30.5cm pin tip to pin tip Q25W2060XG: 2’...
  • Page 8 Crossfade X Height = 0.75” 1.91 cm Q15W2060XG length: 9 3/16” / 23.3cm Q25W2060XG length: 20 5/8” / 52.4cm Q50W2060XG length: 44 5/8” / 113cm Q75W2060XG length: 68 5/16’ / 174cm Q100W2060XG length: 92’ / 234cm Illuminant technical data Diode set 1: 2000K, duv = 0.0055 (2/3 to ¾ Minus Green correction required for neutral CCT) Intermediary CCT: 3000K, duv = -0.007 (1/4 Plus Green correction required for neutral CCT)
  • Page 9: Physical Installation

    Fixture installation configurations and instructions 1. The crossfade lamps will fit any typical T12 clips as well as Quasar Science T12-sized Q-Block mounting blocks (QBK). 2. Quasar Plates or any other device containing T12 clips or T12 Q-blocks can mount crossfade lamps. 4’ or larger lamps may need zip ties to additionally secure them into the blocks.
  • Page 10: Control

    Crossfade X Control • CCT control • Turn the analog CCT dial to the desired color temperature: • Color temperatures are shown divided by 100 (2000K/100 = 20, 3000K/100 = 30, etc) for legibility and precision marking on the dial Dimming The Q-LED crossfade lamps are capable of dimming down while maintaining color temperature.
  • Page 11: Photometric Data

    Crossfade X Photometric data Model Distance (ft) 2000K (FC /Lux) 2800K (FC / Lux) 3000K (FC / Lux) 3200K (FC / Lux) 4400K (FC / Lux) 5600K (FC / Lux) 6000K (FC / Lux) Q15XG 2 / 0.61 39 / 420...
  • Page 12 Crossfade X Model Distance (ft) 2000K (FC /Lux) 2800K (FC / Lux) 3000K (FC / Lux) 3200K (FC / Lux) 4400K (FC / Lux) 5600K (FC / Lux) 6000K (FC / Lux) Q50XG 25 / 7.62 1.1 / 12 1.4 / 15 1.5 / 16...
  • Page 13: Spectral Data & Metrics

    Crossfade X Spectral Data & Metrics The following illuminant spectral fingerprint data shows the maximum amount ofspectral change at steady state temperature vs cold strike temperature.
  • Page 14 Crossfade X...
  • Page 15: Troubleshooting T8S And Crossfades

    Crossfade X Troubleshooting T8s and Crossfades Light Flickers at Low Levels Since Crossfades and T8's are Triac dimmable lights, most Triacs require a certain power draw to function correctly. If you notice your light flickering on dimmers, try grouping them into larger groups of lights, if possible.
  • Page 16: Warranty

    Quasar Science will pay for: The replacement parts, repair and/or labor costs to correct defects in materials and workmanship. *Service must be provided by Quasar Science or an Authorized Quasar Science Service Center* Quasar Science will not pay for: Damage resulting from accident, misuse or abuse. Acts of God. Any failure that occurs for any other reason than materials and workmanship. Any shipping orhandling costs.
  • Page 17 Crossfade X Certificates EU DECLARATION OF CONFORMITY Videndum Production Solutions Ltd. declares under our sole responsibility, supported by Videndum Production Solutions GmbH - our authorized representative, that the product detailed in this manual conforms with all relevant provisions of the following EU directives: •...
  • Page 18 Crossfade X FCC COMPLIANCE STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation.
  • Page 19: Copyright

    Crossfade X Copyright All rights reserved throughout the world. No part of this document may be stored in a retrieval system, transmitted, copied or reproduced in any way, including, but not limited to, photocopy, photograph, magnetic or other record without the prior agreement and permission in writing of Videndum plc.

This manual is also suitable for:

Q15w2060xgQ25w2060xgQ50w2060xgQ75w2060xgQ100w2060xg
