- Page 1 866.332.2403 (TOLL FREE); 7am – 7pm Pacific Time, Monday-Saturday ASSEMBLY INSTRUCTIONS FOR THE THE DEL NORTE PORCH PAVILION...
- Page 2 P| 1 THE DEL NORTE PORCH PAVILION www.ForeverRedwood.com...
- Page 3 P| 2 THE DEL NORTE PORCH PAVILION www.ForeverRedwood.com...
- Page 4 P| 3 THE DEL NORTE PORCH PAVILION www.ForeverRedwood.com...
- Page 5 All options of posts (No posts decorative trim, vertical posts decorative trim and horizontal posts decorative trim) will be installed in the same way. Step 2: Attach the wall mounted anchors (11) to the wall with ½´´ X 3 ½´´ lag bolts (B). P| 4 THE DEL NORTE PORCH PAVILION www.ForeverRedwood.com...
- Page 6 Step 4: Put up the supports with in-between blocking (3), into the post notches as shown and attach to the posts with the single support bolts. Each part has a series of numbers that indicate where to attach the part with the corresponding number. P| 5 THE DEL NORTE PORCH PAVILION www.ForeverRedwood.com...
- Page 7 Step 5: Attach the single supports to the supports with in-between blocking, use 3/8´´ X 7´´ bolts (C). 3/8´´ X 7´´ Bolts Step 6: Use 5/16´´ x 3´´ lag bolts (A) to attach the wall mounted anchors (11) to the supports. 5/16´´ X 3´´ Lag Bolts P| 6 THE DEL NORTE PORCH PAVILION www.ForeverRedwood.com...
- Page 8 Step 8: Attach the main knee braces (5) to the supports with 3/8´´ x 7´´ bolts (C) and to the posts with 3/8´´ x 9´´ Bolts (F). Each part has a series of numbers that indicate where to attach the part with the corresponding number. 3/8´´ X 7´´ Bolts 3/8´´ X 9´´ Bolts P| 7 THE DEL NORTE PORCH PAVILION www.ForeverRedwood.com...
- Page 9 Step 10: Use 5/16’’ x 3’’ lag bolts (A) to attach the angles (12) to the in-between blockings. Each part has a series of numbers that indicate where to attach the part with the corresponding number. 5/16´´ X 3´´ Lag Bolts P| 8 THE DEL NORTE PORCH PAVILION www.ForeverRedwood.com...
- Page 10 Step 12: Use 3/8´´ x 8´´ bolts (G) to attach the roof panels (7) to the perimeter triangles and 3/8’’ x 10’’ bolts (H) to attach to the central triangle. Each part has a series of numbers that indicate where to attach the part with the corresponding number. 3/8´´ X 10´´ Bolts 3/8´´ X 8´´ Bolts P| 9 THE DEL NORTE PORCH PAVILION www.ForeverRedwood.com...
- Page 11 Step 14: Attach the roof fascia’s (8) to the roof panels with 6’’ x 1 5/8’’ deck screws (I). Each part has a series of numbers that indicate where to attach the part with the corresponding number. P| 10 THE DEL NORTE PORCH PAVILION www.ForeverRedwood.com...
- Page 12 Step 15: Finally, attach the boots (9) to each post with 3’’ deck screws (E). 3´´ Deck Screws P| 11 THE DEL NORTE PORCH PAVILION www.ForeverRedwood.com...
- Page 13 This completes the Pavilion assembly. Hope you enjoy your set for many decades. If you ever have a problem or a question, don't hesitate to call us (866 332 2403) or email us. We are here to support you. P| 12 THE DEL NORTE PORCH PAVILION www.ForeverRedwood.com...
