- Page 1 866.332.2403 (TOLL FREE) (707) 640.29.05 (Option 4) Direct Line for the Design Department; 7am – 7pm Pacific Time, Monday-Saturday ASSEMBLY INSTRUCTIONS FOR THE DEL NORTE OUTDOOR KITCHEN PAVILION...
- Page 2 Insert the carriage bolts into the holes and lightly tap with a hammer until the square neck fit in the wood piece and the bolt head must flush with the wood piece. Finally, place the washer and the nut and carefully tighten it using a ratch with the necessary socket or a wrench. P| 1 DEL NORTE OUTDOOR KITCHEN PAVILION www.ForeverRedwood.com...
- Page 3 Place the washers in their lag bolts. After that, insert the lag bolts into the holes and carefully tighten it using a ratch with the necessary socket. Use the washers only for the Wood Pieces. To install the deck screws. Insert the deck screws into the holes and carefully tighten it using a drill. P| 2 DEL NORTE OUTDOOR KITCHEN PAVILION www.ForeverRedwood.com...
- Page 4 P| 3 DEL NORTE OUTDOOR KITCHEN PAVILION www.ForeverRedwood.com...
- Page 5 P| 4 DEL NORTE OUTDOOR KITCHEN PAVILION www.ForeverRedwood.com...
- Page 6 P| 5 DEL NORTE OUTDOOR KITCHEN PAVILION www.ForeverRedwood.com...
- Page 7 P| 6 DEL NORTE OUTDOOR KITCHEN PAVILION www.ForeverRedwood.com...
- Page 8 P| 7 DEL NORTE OUTDOOR KITCHEN PAVILION www.ForeverRedwood.com...
- Page 9 ½” x 6” lag bolts 5/16” x 3” Lag Bolts Step 2: Attach the metal plaque (12) to the post with ½” x 3” lag bolts (C). ½” x 3” lag bolts P| 8 DEL NORTE OUTDOOR KITCHEN PAVILION www.ForeverRedwood.com...
- Page 10 Step 4: Attach the single supports to the supports with in-between blocking (3), use 3/8” x 6 ½” bolts (D). After that, return to the bolts described in the step 3 and tighten fully. Check the marked numbers on each support with in-between blocking and place as drawings shown. 3/8” x 6 ½” bolts P| 9 DEL NORTE OUTDOOR KITCHEN PAVILION www.ForeverRedwood.com...
- Page 11 Step 6: Attach the main knee braces (8) to the supports with 3/8” x 6 ½” bolts (D) and to the posts with 3/8 X 9” Bolts (E) with washer and nuts. Check the marked numbers on each main knee brace and place as drawings shown. 3/8” x 6 ½” bolts 3/8 X 9” Bolts P| 10 DEL NORTE OUTDOOR KITCHEN PAVILION www.ForeverRedwood.com...
- Page 12 Step 8: Attach the perimeter Roof Trusses (4) to the posts with 3/8” x 6 ½” bolts (D) with washer and nuts. Check the marked numbers on each roof truss and place as drawings shown. 3/8” x 6 ½” bolts P| 11 DEL NORTE OUTDOOR KITCHEN PAVILION www.ForeverRedwood.com...
- Page 13 Step 10: Attach the secondary knee braces (9) to the Roof Trusses with 3/8” x 6 ½” bolts (D) and to the posts with 3/8” x 9” Bolts (E) with washer and nuts. Check the marked numbers on each secondary knee brace and place as drawings shown. 3/8” x 6 ½” bolts C-10 3/8” X 9” Bolts P| 12 DEL NORTE OUTDOOR KITCHEN PAVILION www.ForeverRedwood.com...
- Page 14 Step 12: Attach the front roof trims (6) to the roof boards with 2” deck screws (J). Check the marked numbers on each roof trims and place as drawings shown. 2” deck screws P| 13 DEL NORTE OUTDOOR KITCHEN PAVILION www.ForeverRedwood.com...
- Page 15 Step 14: Attach the fascias (7) to the roof trusses with 1 5/8” deck screws (L). Check the marked numbers on each fascia and place as drawings shown. 1 5/8” deck screws P| 14 DEL NORTE OUTDOOR KITCHEN PAVILION www.ForeverRedwood.com...
- Page 16 5/16” x 3 ½” bolts Step 16: Finally, attach the boots (10) to each post with 3’’deck screws (N). 3´´ Deck Screws P| 15 DEL NORTE OUTDOOR KITCHEN PAVILION www.ForeverRedwood.com...
- Page 17 This completes the Pavilion assembly. Hope you enjoy your set for many decades. If you ever have a problem or a question, don't hesitate to call us (866 332 2403) or email us. We are here to support you. P| 16 DEL NORTE OUTDOOR KITCHEN PAVILION www.ForeverRedwood.com...
