1. Propellers
2. Motors
3. ESCs
4. Aircraft Front Indicators (on three front arms)
5. Frame Arms
6. Folding Detection Sensors (built-in)
7. Hoses
8. Sprinklers
9. Nozzles
10. Electromagnetic Exhaust Valves
11. Omnidirectional Digital Radar

Remote Controller

The Smart Controller 3.0 uses DJI OcuSync 2.0 transmission technology, has a max transmission distance of up to 7 km*,
and supports Wi-Fi and Bluetooth. The remote controller has a 5.5-inch bright, dedicated screen and comes with the
updated DJI Agras app built-in, delivering a smooth and easy-to-use experience. When the RTK dongle is connected to
the remote controller, users can plan operations to centimeter-level precision. The Multi-Aircraft Control mode* of the
remote controller can be used to coordinate the operation of up to five aircraft at the same time, enabling pilots to work
efficiently. Both the built-in battery and external battery can be used to supply power to the remote controller. The
remote controller has a working time of up to 4 hours, making it ideal for long and high-intensity operations.
1. Antennas
2. Back/Function Button
3. Control Stick
4. RTH Button
5. Button C3 (customizable)
6. Flight Mode Switch
7. Status LED Descriptions
8. Battery Level Indicators
9. 5D Button (customizable)
The figure below shows the function that each control stick movement performs and uses Mode 2 as an example. In
12. Upward Radar
13. Heat Sinks
14. Liquid Level Gauge
15. Spread Tank
16. Battery Compartment
17. Forward FPV Camera
18. Backward FPV Camera
19. Landing Gear
20. OCUSYNC
21. Onboard D-RTK
22. Aircraft Status Indicators (on three rear arms)
10. Power Button
11. Confirm Button
12. Touch Screen
13. USB-C Charging Port
14. Dongle Compartment Cover
15. Spray Rate Dial
16. Spray Button
17. HDMI Port
18. microSD Card Slot
TM
Antennas
TM
Antennas
19. USB-A Port
20. FPV/Map Switch Button
21. Work Efficiency Dial
22. Air Outlet
23. Button C1 (customizable)
24. Button C2 (customizable)
25. Battery Cover
26. Battery Cover Release Button
27. Handle
