Parameter
Biasing current B (solenoid
A + B)
PWM frequency, relative, f
Universal valves: absolute
Command value inversion
Inv
Function:
Digital (enable) input DI
DI
t
Z/B
G
S
DI
t
Z/B
G
S
LED Description
indicator
lamps
A
DI
t
Z/B
G
S
v
DI
t
PWM
Z/B
G
S
t
Command value inversion
DI
t
Z/B
G
S
Digital (enable) input
DI
t
Z/B
G
S
1) Ramp times effective only when 4Q operating mode is activated
2) Function available only on VT-MSPA2-2X/..
3) The function of the digital input is XOR-linked to the internally selected state
8.7 Restoring the VT-MSPA...-2X to factory settings
This function is available exclusively directly upon switching on the operating
voltage. It resets all customer-specific parameters of the set valve to the factory
settings.
The module has to be de-energized.
1. Press and hold [Set] and switch on the supply voltage.
The LEDs signal the status shown on the left.
1. After some time, the LEDs switch to the status shown on the left.
The module is restored to factory settings.
2. Release [Set].
Restoring to factory settings is completed.
Editable
parameter
Biasing current
B
of solenoid A and
solenoid B
v
PWM frequency,
relative
Universal valves,
absolute
ON/OFF
1: Enable input
(default)
2: Inversion
3: Ramp ON/
3)
OFF
4: Changeover
simple ramp/4Q
ramp 3)
RE 30232-B/08.2020, Valve amplifier VT-MSPA, Bosch Rexroth AG
Commissioning
Output at test jack v
0...step height %:
0...5.0 V
80 % to 120 % of the nominal
frequency
0.8 V...1.2 V
0.95 V...5.05 V (100 Hz/V)
95 Hz ... 505 Hz
ON: +1 V
OFF: 0 V
1: 1 V
2: 2 V
2) 3) 3: 3 V
4: 4 V
29/36
