NOVOFLEX MiniConnect MR User Manual

Technical Data: MC-MR
Hight x Base Ø 20 x 53 mm (0.8 x 2.1 in)
Connection tripod side 1/4" and 3/8"
Connection camera side 1/4"
Weight 100 g (0.22 lbs)
Information
For more information, advice and tips concerning our products contact your photo dealer,
the distributor of NOVOFLEX products in your country (have a look at "Where to buy"
section at our website to find your distributor) or visit our website www.novoflex.com
For personal advice about possible accessories which is suitable for your NOVOFLEX
product please contact the following phone number or send us an E-mail.
NOVOFLEX Tel.: +49 8331 88888
NOVOFLEX E-Mail: mail@novoflex.com
© NOVOFLEX Präzisionstechnik GmbH
Phone +49 8331 88888, Fax +49 8331 47174
Email mail@novoflex.com, Internet www.novoflex.com
Brahmsstraße 7
D-87700 Memmingen
MiniConnect MR
USER MANUAL
Congratulations on your acquisition of the
MiniConnect MR quick-release unit. Whilst
you should have no difficulty in using your
MiniConnect MR, you may find the following
explanations useful.
1 2
3
Lateral view
Product description
The MiniConnect MR is a very practical,
small and extremely light quick-release unit
for the popular, round MiniConnect coupling
pieces. It is the more compact version of the
MiniConnect MC quick-release unit, which
dispenses with automatic locking in favor of
lower weight and smaller dimensions.
View from above
4
5
Bottom view
Nomenclature
1 1/4" Release piece
2 Base plate
3 Clamping lever
4 Headless screw
5 3/8" thread hole incl.
adapter to 1/4"
