Detail Descriptions For Periodic Inspection - Direct Healthcare Group SystemRoMedic RoWalker400 Service Manual

Detail descriptions for Periodic inspection

7
13
6
10
1
2
1. Frame
2. Castors with brake
3. Castors with direction lock
4. Footpedal for leg spread adjustment
5. Leg support
6. Gas spring
7. Control for hight adjustment
8. Seat support
9. Handles
10. Locking clamp
11. Locking handle
12. Arm support
13. Star knob for arm support
SystemRoMedic
TM
9
4
12
11
5
3
Page 8
Page 8
Page 8
Page 8
Page 9
Page 9
Page 9
Page 9
Page 10
Page 10
Page 10
Page 10
Page 10
8
7
