2-5-3 PCI Express Slot
The P35 chipset Based motherboard series offer one 16-LANE PCI-Express x16 graphics slot
of 4Gbyte/sec data transfer rate at each relative direction which get 3.5 times of bandwidth
more than AGP8X and it's up to a peak concurrent bandwidth of 8Gbyte/sec at full speed to
guarantee the performance and compatibility of GPU graphics add-in cards. The whole series
carry three 32-bit PCI slots guarantee the rich connectivity for the I/O peripheral devices. Two
PCI Express x1 I/O slots offer 512Mbyte/sec concurrently, over 3.5 times more bandwidth
than PCI at 133Mbye/sec, tackling the most demanding multimedia tasks nowadays.
PCI-E x1 slot
PCI-E x1 Slot
PCI-E x16
