Specification

Spec
Design
Chipset
CPU Socket
LGA775
Memory Socket
Expansion Slot
Integrate IDE and
Serial ATA2 RAID
Gigabit LAN
8CH-Audio
BIOS
Multi I/O
∗ ATX form factor 4 layers PCB size: 30.5x22.0cm
∗ Intel P35 Chipset
∗ Intel ICH7 chipset
∗ Support Intel Pentium 4, Celeron（
Pentium D, Core 2 Duo and Core 2 Quad 775-Land LGA
Package utilizes Flip-Chip Land Grid Array (FCLGA) package
processor
∗ Support FSB Frequency 800 / 1066/1333MHz
∗ 240-pin DDR2 Module socket x 4
∗ Support 4 pcs DDR2 667 /DDR2 800MHz DDR2 Modules
Expandable to 8.0GB
∗ Support Dual channel function
∗ PCI-Express x16 slot 1pcs ;
∗ PCI-Express x1 slot 2pcs delivers up to 512MB/s concurrent
bandwidth
∗ 32-bit PCI slot x 3pcs
∗ The Intel ICH7 supports four Serial ATA ports provide 3.0 Gb
/sec data transfer rate.
∗ One IDE controllers support PCI Bus Mastering, ATA
PIO/DMA and the ULTRA DMA 33/66/100 functions that
deliver the data transfer rate up to 100 MB/s for 2 IDE
Devices;.
∗ Integrated Realtek RTL8111B/RealtekRTL8111C PCI-Express
Gigabit LAN function.
∗ Supports Fast Ethernet LAN function provide 10Mb/100Mb/
1Gb /s data transfer rate
∗ Realtek ALC888 Azalia 8-channel Audio Codec integrated
∗ Support 8-channel 3D surround & Positioning Audio
∗ Audio driver and utility included
∗ Award 8MB SPI Flash ROM
∗ PS/2 keyboard and PS/2 mouse connectors
∗ Floppy disk drive connector x1
∗ Serial Port x1
∗ Serial Port header x1
∗ Parallel header x1
∗ Coaxial In/Out connector x1
∗ USB2.0 port x 4 and headers x2 (connecting cable optional)
∗ Audio connector (Line-in, Line-out, MIC/ 8CH Audio)
Description
FSB 800/1066/1333 MHZ）
