automatic detection of the optimal number of block read/writes per sector the drive can

support. The settings are: Enabled, Disabled.

3-7-2

Onboard Device Function

Onboard PCIE LAN Controller

Onboard PCIE LAN Boot Rom

High Definition Audio

USB Host Controller

USB 2.0

Function

USB Keyboard Legacy Support

USB Mouse

Legacy Support

USB Storage Legacy Support

↑↓→← Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help

F5:Previous Values

Onboard PCIELAN Function

Setting to [Enabled] allows the BIOS to auto-detect the LAN controller and enable it. Setting

options:[ Enabled] and [Disabled] .

High Definition Audio

The selection for you to choose the embedded Audio function or 3

installed. The settings are: Enabled and Disabled.

USB 2.0 Controller

This setting allows you to enable/disable the onboard USB controller. Selecting [Enabled]

enables the system to support USB 2.0 spec. setting options:[Disabled],[Enabled].

USB Keyboard/Storage Support

Select Enabled if your system contains a Universal Serial Bus (USB) controller and you have

a USB keyboard. The settings are: Enabled, Disabled.

3-7-3

OnChip Super IO Function

Onboard FDD Controller

UART1 Resources Select

UART2 Resources Select

﹡ UART2 Mode Select

﹡ IR Duplex Mode

Onboard Parallel Port

Parallel Port Mode

﹡ ECP Mode Use DMA

↑↓→← Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help

F5:Previous Values

Onboard FDD Controller

Select Enabled if your system has a floppy disk controller (FDD) installed on the system board

and you wish to use it. If you install add-on FDC or the system has no floppy drive, select

Disabled in this field. The settings are: Enabled and Disabled.

UART2 Mode Select

This item allows you to determine which InfraRed(IR) function of the onboard I/O chip, this

functions uses.

IrDA Duplex Mode

Phoenix – AwardBIOS CMOS Setup Utility
