  • Page 1 TR1350 Rework System Instruction Manual Thank you for purchasing our production. Keep this manual handy for future reference.

  • Page 2: Table Of Contents

    CONTENTS 1 Safety Instruction ..............................2 2 Introduction ................................. 3 3 Characteristic ............................... 3 4 Technical Data ..............................3 5 Part Description ..............................4 6 Connection and Dimension..........................5 6.1 Connection ..............................5 6.2 Dimension ..............................5 7 Operation Process ..............................6 7.1 Turn ON/OFF ..............................

  • Page 3: Safety Instruction

    1 Safety Instruction  Please read this manual carefully before use.  This system uses rated voltage and frequency.(Please refer to the trademark on the back of the system.)  The handle is placed on the holder, the system will sleep automatically when the temperature is below 100 ℃.

  • Page 4: Introduction

     Equip with the DC brushless motor.  Light handle, comfortable to use and ESD design.  With RS 485 communication function. 4 Technical Data Item Data Mode TR1350 Voltage 220V AC 50/60Hz Power 1300W Display Hot Air Temperature Range 100℃～500℃...

  • Page 5: Part Description

    Weight About 5.3kg ★NOTE: Ensure that your power supply data agrees with the information on the nameplate of the machine! 5 Part Description Item Part Name Operation panel Hot air gun holder Hot air gun protective cover Hot air gun Nozzle ...

  • Page 6: Connection And Dimension

    6 Connection and Dimension 6.1 Connection Item functions: 1. Hard Power Switch: it’s a power connecting or disconnecting rework system. 2. Power inlet module: connect the outlet of the power supply 220V AC power line into power inlet module. 3. ESD socket 4.

  • Page 7: Operation Process

    7 Operation Process 7.1 Turn ON/OFF 1. Hard Power ON: Turn on the equipment by switch on hard power switch, when it is connected outlet power supply. The Figure 1 will appear, press any button to enter into Main Menu, see following picture: POWER Touch Key Figure 1...

  • Page 8: Break Sleep Method

    7. 4 Break Sleep Method 1: The handle is placed on the holder, the system will sleep automatically when the temperature is below 100 ℃, and remove it from holder to break sleep. 2: The handle is not placed on the holder, the sleep is break when you press “1” button. 3: Press the foot switch to break sleep.
  • Page 9 Buzzer symbol Shows the hot air volume. Shows the temperature timing, it is preset timing down to 0. Shows temperature unit (℃/℉) Shows the heating element is heating. Show the heating element preset temperature value. Shows the heating element is cooling. Shows lock or unlock status.

  • Page 10: Data Set Menu

    8.2 Data Set Menu 1. Press and hold “2” & “3” buttons to enter into System Set Menu, see above picture. 2. Press “1” button to move the cursor to the required item (such as Data Set) and press “3” button to enter into Data Set Menu, see following picture.

  • Page 11: System Set Menu

    4. Press “2” button to save. 8.3 System Set Menu Press “+” or “-” button to move the cursor to the SYS SET. 8.3.1 Password 1. Press “+” or “-” button to move the cursor to the Password, and the default activated menu is Password.

  • Page 12: Alarm Temperature

    8.3.3 Alarm Temperature 1. Press “+” or “-” button to move the cursor to the Alarm Temp. 2. Press “3” button to activate Alarm Temp. 3. Press “1” button to select alarm temperature mode (ON/OFF). 4. Press “+” or “-” button to change temperature value, the preset value is 2～99℃. 5.

  • Page 13: Address

    1. Press “+” or “-” button to move the cursor to the Key Tone. 2. Press “3” button to activate Key Tone. 3. Press “1” button to select Key Tone mode (ON/OFF), and press “3” button to save. 4. Press “2” button to back. 8.3.6 Address 1.

  • Page 14: Error Symbol

    10 Error Symbol Various error messages will be displayed when there is something wrong with the equipment. “NO Handle”: handle is not inserted. “Sensor Error”: temperature sensor error. “Room Sensor Error”: temperature offset sensor error. “Heater Error”: heating element error. “Hot Fan Run Error!”: hot air fan error.
  • Page 15 QUICK INTELLIGENT EQUIPMENT CO., LTD. ADD: NO.11, FengXiang Road, Wujin High-Tech Industrial Development Zone, Jiangsu, China TEL: 86-519-86225678 FAX: 86-519-86558599 POSTCODE: 213167 WEBSITE: www.quick-global.com...
