- Page 1 MANUAL ZIGBEE CONFIGURATION BINDING BETWEEN THE GWA1531 ROLLER SHUTTER ACTUATOR AND THE GWA1501 INTERFACE TECHNICAL MANUAL...
- Page 2 page 2 | Z | TECHNICAL MANUAL: BINDING BETWEEN GWA1531 AND GWA1501...
-
Page 3: Table Of Contents
CONTENTS CONTENTS ................................3 AIM OF THIS PUBLICATION ..........................4 ZIGBEE KEY – USEFUL TERMS .......................... 4 TECHNICAL FILES ..............................5 DIMENSIONS ................................6 BREAKDOWN OF THE ZIGBEE DEVICES ......................7 ELECTRIC DIAGRAMS ............................8 CONFIGURATION ..............................9 : ..................... 9 REATING AND JOINING TO THE EE NETWORK : .......................... -
Page 4: Aim Of This Publication
AIM OF THIS PUBLICATION This manual is designed for the installer responsible for configuring the ZigBee system. It explains how to make the binding between the GWA1531 and GWA1501 devices. ZIGBEE KEY – USEFUL TERMS Binding: The association between an actuator and a sensor in order to carry out a certain function Coordinator: The ZigBee device that carries out the following tasks:... -
Page 5: Technical Files
TECHNICAL FILES GWA1531 Roller shutter actuator ATEGORY 230V AC / 50Hz UPPLY VOLTAGE 6A-230V AC (in accordance with 60669-2-1) OUTPUT CURRENT (W): 2.3W DISPERSIBLE POWER 500W MOTOR POWER 8 dBm UTPUT POWER IP20 EGREE OF PROTECTION [-5°; +45°C] PERATING TEMPERATURE [-25°;... -
Page 6: Dimensions
DIMENSIONS GWA1531 GWA1501 page 6 | Z | TECHNICAL MANUAL: BINDING BETWEEN GWA1531 AND GWA1501... -
Page 7: Breakdown Of The Zigbee Devices
BREAKDOWN OF THE ZIGBEE DEVICES GWA1501 A1. DIP-switch with 4 one-way switches A2. Miniature button key for joining functions A3. Status LED GWA1531 A1. DIP-switch with 3 one-way switches A2. Miniature button key for joining functions A3. Status LED TECHNICAL MANUAL: BINDING BETWEEN GWA1531 AND GWA1501 | page 7... -
Page 8: Electric Diagrams
ELECTRIC DIAGRAMS GWA1501 I1. Channel 1 input C1. Channel 1 common wire I2. Channel 2 input C2. Channel 2 common wire GWA1531 N. Power supply neutral L. Power supply phase O▲. NO output with powered contact for the up movement O▼. -
Page 9: Configuration
CONFIGURATION If the ZigBee network hasn't yet been created, proceed as follows: 1. Choose which device will have the role of coordinator 2. Activate the procedure to create the ZigBee network via the coordinator 3. After creating the network, activate Permit Join 4. -
Page 10: Actuator Parameters (Gwa1531)
ACTUATOR PARAMETERS (GWA1531) Shutter Venetian blind NB: this setting only takes effect on the local input of the actuator; the setting that will be made on the interface will in any case be executed by the actuator. How to set the downward stroke time of the roller shutter/Venetian blind The downward stroke time can be modified as follows: (“fully Bring the roller shutter/Venetian blind to the completely open position... -
Page 11: How To Set The Number Of Slat Regulation Steps When Opening The Venetian Blind
How to set the number of slat regulation steps when opening the Venetian blind The number of slat regulation steps on opening can be modified as follows: 1. Bring the Venetian blind slats to the completely closed position 2. Bring the dip-switches to the position shown to enter the mode for configuring the number of slat regulation steps on opening 3. -
Page 12: Interface Parameters (Gwa1501)
INTERFACE PARAMETERS (GWA1501): OSITION HANNEL MODE HANNEL MODE Independent push-button Independent push-button Combined push-buttons Combined push-buttons One-way switch (toggle) One-way switch (toggle) One-way switch (on/off) One-way switch (on/off) Scene Scene Independent push-button One-way switch (toggle) Scene Independent push-button Timed push-button Independent push-button Depending on the operating mode selected and the actuators associated, the behaviour of each channel upon the closure/opening of the corresponding input is as follows:... -
Page 13: Interface (Gwa1501) Factory Reset
INTERFACE (GWA1501) FACTORY RESET Press and hold the Permit Join activation push-button (A2) for at least 10 seconds. The status LED will flash red and green alternately for 3 seconds, then become red fixed. ACTUATOR (GWA1531) FACTORY RESET Press and hold the Permit Join activation push-button (A2) for at least 10 seconds. The status LED will flash red and green alternately for 3 seconds, then become red fixed. - Page 14 page 14 | Z | TECHNICAL MANUAL: BINDING BETWEEN GWA1531 AND GWA1501...
