Dukane 202 Specifications

Camera 202
• Super High Resolution Image XGA
(1024 X 768)
• Full Color
• Display Image on PC Monitor or
with Projector
• Exceptional Image Quality
• Easy to use
• Push Button Control of Camera or
PC Throughput
• Fluorescent Light for Correct
Illumination
FEATURES
Camera 202 lets you capture images with a resolution never before possible. The image is
computer screen quality and must be shown on a PC monitor or projected. The camera is
ideal for classrooms, lecture halls, podiums, teleconferences, or anywhere an object must
be viewed by a group. It provides the ability to show macroscopic objects, a printed page, or
the entire room with breathtaking detail. It can be easily
transported and connected in less than a minute. It will function as
a document camera allowing both a computer and the camera to
share the same cable to a projector. Camera 202 is the ideal
partner to a Dukane ImagePro™ projector.
The Camera 202 inputs are easily accessible.
Connecting your computer is quick and easy.

SPECIFICATIONS

1024 x 768 Pixel Image (XGA) • Auto Adjusting Light Range • Automatic White Balance •
Manual 6.7mm FL Lens • Easy Focus Wheel • 0.5 inch to Infinity Focal Range • Up to
100X Magnification • Moveable head and Extendable Arm • Selectable XGA or SVGA
output • Easy Fold-up Arm • Attachable Fluorescent Lamp • Output Switchable between
Camera or PC • Standard PC Input • Switchable 3X Digital Zoom • Switch for Image
Rotation • Switch for Inverse/Black & White/Data Images • Switch & Power "ON"
Indicator • 6ft Power Cord • 6ft DC Power Cord with Transformer • Output & Input is
15pin D-Sub • Weight 3.3 lbs • Shipping Weight 9.9 lbs• UL/C-UL listed • Five Year
Warranty
PROJECTING YOU INTO THE FUTURE
The Camera 202 folds
down in size to save space
Audio Visual Products
Www.dukcorp.com/AudioVisual/
Form # 11534-B-05
