INSTALLATION GUIDE
ALARM AND REMOTE STARTER • MODEL RS602E
CONTENTS
System Features .......................................
System Components .....................................
Tools Required ........................................
Technical Assistance ..................................
Before You Begin ......................................
Precautions ...........................................
Testing Your Wires ....................................
Making Connections ..................................
Locating & Making Connections ........................ 4-6
Neutral Safety Switch ................................. 6
Antenna Placement .....................................
Factory Anti-Theft System.............................. 7
Optional Connections ................................ 8-9
Testing Door Locks ....................................
Connecting Door Locks ................................ 10
Operating Instructions............................. 10-11
Programming Instructions........................... 11-12
All tech personnel are expertly qualified to answer any technical questions.
Technicians are available Monday through Friday from 9:00 a.m. until 8:00 p.m. and Saturday 10:00 a.m. until 4:00 p.m.
OWNER'S GUIDE
Technical Assistance
Address
288 Canton Avenue • Wintersville, Ohio 43953
Telephone
Phone: 740-264-4710 • 800-878-8007 • Fax: 740-264-7306
•
1
1
1
2
2
2
2
3-4
6
9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS602E and is the answer not in the manual?

Questions and answers

Related Manuals for Bulldog Security RS602E

Summary of Contents for Bulldog Security RS602E

  • Page 1: Table Of Contents

    INSTALLATION GUIDE OWNER’S GUIDE ALARM AND REMOTE STARTER • MODEL RS602E CONTENTS System Features ... System Components ... Tools Required ... Technical Assistance ... Before You Begin ... Precautions ... Testing Your Wires ... Making Connections ... Locating & Making Connections ... 4-6 Neutral Safety Switch ...

  • Page 2: System Features

    SYSTEM FEATURES 2 Four-Button Extended Range Remotely start your car to run the heater or air conditioning from an extended distance. Remote Control Keyless Entry Remotely locks and unlocks your power door locks. Built In Alarm Features Provides door and hood protection. Door Trigger Protection Provides protection when doors are opened Shock Sensor Input...

  • Page 3: Technical Assistance

    It is computer controlled and manufactured in the U.S.A. The dependability and variety of features make Bulldog Security the leader in the industry. Enjoy your new remote starter for years to come! This remote system is designed to start your vehicle by sending a command signal from the remote transmitter or by programming automatic temperature or timed start.

  • Page 4: Testing Your Wires

    GENERAL MOTORS REAR WHEEL DRIVE VEHICLES AND DODGE DAKOTAS All General Motors rear wheel drive vehicles and Dodge Dakotas built prior to 1996 do not have an electrical Neutral Safety switch. They have a mechanical neutral safety switch. The mechanical neutral safety switch operates as follows.

  • Page 5: Follow These Instructions

    MAKING END TO END CONNECTIONS 1. When tying two separate wires together at their ends, strip back 1” of insulation on both wires and separate the strands of wire as shown below. 2. Twist upper wires together, twist lower wires together as shown. 3.
  • Page 6 IGNITION WIRE(S) (+12V in run and crank position only) The ignition wire(s) are also located in the main harness coming from the ignition switch. Probe each wire with your test light, the correct wire(s) will show +12V only when the ignition switch is in the RUN AND CRANK positions only.

  • Page 7: Neutral Safety Switch

    HOOD PIN SWITCH This feature will keep the engine from starting or shut off the engine when the hood is opened. Locate a good chassis ground, if at all possible do not install the pin switch in the rain gutter. Drill a 5/16 hole, insert the pin switch into the hole and tighten.

  • Page 8: Factory Anti-Theft System

    FACTORY ANTI-THEFT SYSTEMS FOR GENERAL MOTORS CARS ONLY System 1: PASSKEY I and II system (1985 and up). This system has a resistor pill in the key. Measure resistance of the pill using a test meter. A bypass module is available, part #VATS-WR module. System 2: PASSLOCK I and II system (1995 and up).

  • Page 9: Dome Light Supervision

    If your vehicle is a (+) positive door pin connect the BLACK WITH WITH YELLOW STRIPE wire from the 18- pin harness to the door pin wire. Follow the instructions on page 11 to program your unit to work with a (+) positive door pin.

  • Page 10: Testing Door Locks

    HORN HONK OUTPUT (-) (Optional part #775) The existing horn wire will usually be found in the main ignition switch harness in the steering column. Probe for a wire which will remain neutral (in some cases may show a (+) positive). When the horn is pressed this wire will test as a ground or (-) negative.

  • Page 11: Connecting Door Locks

    Testing Switch Wire and Motor Wires Before connecting, you must now determine which wire is the switch wire and which is the motor wire. Cut both the lock and unlock wires in half. Start with both of the lock wires by placing the clip end of your test light to ground, hold the door lock switch in the lock position, make sure you are using the master switch (usually on the driver’s door) and probe both lock wires looking for voltage.

  • Page 12: Installation Programming

    INSTALLATION PROGRAMMING: Programming Tach/Tachless Start Press and hold the brake, then press and hold Button #3 (trunk) until the parking lights flash three (3) times. Release Button #3. Press and release Button #4, the parking lights will flash once. The unit is now in Tachless Start Mode.

  • Page 13: How To Use Your Remote Transmitter

    NOTE: Only Cold and Hot Start functions can be enabled at the same time. If button #1 is pressed for programming, Cold/Hot Start is disabled. When Buttons #2 and #3 are pressed, then the Automatic and Low Voltage Starts are disabled. SPECIAL PROGRAMMING MODE: Valet Mode On Press and hold the brake, turn Ignition Key to the Run position.
  • Page 14 Keyless Entry Operation Press button #2 (lock/unlock), the parking lights will flash once and the doors will lock. Press button #2 again, the parking lights will flash twice, the doors will unlock, and the parking lights will remain on for one minute or until you turn the ignition on or press the brake. Dome Light Supervision Option The remote starter includes an optional output that can be used to illuminate the dome light when pressing button #2 and unlocking your power door locks.
