INSTALLATION GUIDE
CONTENTS
System Features ...........................................
System Components ...........................................
Technical Assistance ........................................
Before You Begin ............................................
Precautions .................................................
Making Connections ........................................
Locating & Making Connections .............................. 5-7
Optional Connections ...................................... 7-8
Antenna Placement ...........................................
Wiring Diagram ..............................................
How to use Your Remote Transmitter ........................ 9-10
Operating Instructions................................... 10-11
All tech personnel are expertly qualified to answer any technical questions.
Technicians are available Monday through Friday from 9:00 a.m. until 8:00 p.m. and Saturday 10:00 a.m. until 4:00 p.m.
OWNER'S GUIDE
SECURITY SYSTEM
PRO-SERIES 7002
Technical Assistance
Address
288 Canton Avenue • Wintersville, Ohio 43953
Telephone
Phone: 740-264-4710 • 800-878-8007 • Fax: 740-264-7306
•
1-2
2
2
2
3
3-4
8
9
Advertisement
Table of Contents
Related Manuals for Bulldog Security Pro-Series 7002
Summary of Contents for Bulldog Security Pro-Series 7002
-
Page 1: Table Of Contents
Technicians are available Monday through Friday from 9:00 a.m. until 8:00 p.m. and Saturday 10:00 a.m. until 4:00 p.m. 288 Canton Avenue • Wintersville, Ohio 43953 Phone: 740-264-4710 • 800-878-8007 • Fax: 740-264-7306 • SECURITY SYSTEM PRO-SERIES 7002 Technical Assistance Address Telephone... -
Page 2: System Features
SYSTEM FEATURES 2 Long Range Four-Button Remotes Hand-held, easy to use and lets you operate the system from an extended distance. Keyless Entry with onboard relays Two onboard relays are provided to work any vehicle’s door locks without additional parts. This feature will remotely lock or unlock your power door locks even if the engine is running or the alarm is in valet mode. -
Page 3: System Components
On-Board Parking Light Relay Built in relay provides a positive (+) parking light output. No external relay needed. On-Board Dual Stage Shock Sensor Saves time in installation. Not sensitive to temperature or aging, but extremely sensitive to shock or glass breakage. Ignition Detection Adds protection by sounding the siren and flashing the lights if the ignition wire is hot- wired or turned on when the system is armed, even if the current sensor or door switch wires... -
Page 4: Precautions
PRECAUTIONS SAFETY FIRST! A periodic safety check is recommended to ensure that your system is in proper working order. DO NOT use mechanical wiring connections, such as crimp or snap together wire connectors. Instead, follow the instructions on pages 3-4 DO NOT disconnect the battery if the vehicle has an anti-theft-coded radio or is equipped with an airbag. - Page 5 6. Use electrical tape to wrap. Be sure to cover the wire about two inches on either side of the connection. First pull the wire that you have just connected along side the wire you connected to, tape and wire tie them together. Use this method for all connections. CAUTION: All wires must be wrapped with tape and wire tied.
-
Page 6: Locating & Making Connections
LOCATING & MAKING CONNECTIONS MOUNTING AND CONNECTING THE SIREN Select a location under the vehicle's hood for the siren. •The mounting location should be solid and have no moving parts nearby. •For the loudest sound, the siren should point down. •The siren should not point straight up as moisture could collect in the siren horn. - Page 7 4.Most vehicles use a (-) negative switch, but if your does not, you will need to test for a (+) positive door pin switch. 5.Connect your meter or test light's negative lead to a good solid chassis ground. Use the positive lead or other lead probe to the door pin switch wire.
-
Page 8: Optional Connections
NEGATIVE OUTPUTS Negative output #2, Button #2 - the WHITE WITH YELLOW STRIPE wire is used to operate the car starter (optional), etc. The negative output will pulse for one half second by pressing transmitter Button #2. Negative output #3, Button #3 - the WHITE WITH RED STRIPE wire is used to operate a power trunk release, window roll-up module, etc. -
Page 9: Antenna Placement
“Type A” (+) Positive (5-pin harness) GREEN/BLACK Unlock GREEN/WHITE Not Used RED/BLACK FUSE BLUE/BLACK Lock BLUE/WHITE Not Used NOTE: Once you have made the connections for the 5-pin door lock harness, you will need to plug the door lock harness into the main module 5-pin plug on the front of the unit. “Type C”... -
Page 10: Wiring Diagram
WIRING DIAGRAMS FIGURE 1 1. Red (+) 12 Volt Constant 5-Pin Door Lock Harness 2. Black Chassis Ground Connector 3. Grey (+) Siren Output 4. White/Red Button #3 / Channel #3 (-) Output: Window Rollup, etc. 200 mA Max 5. White/Yellow Button #2 / Channel #2 (-) Output: Remote Starter, etc. -
Page 11: Operating Instructions
Car Finder While the system is armed, press and release Button #3. The alarm will chirp 6 times and the parking lights will flash. This is used to locate your vehicle in a crowded parking lot. Optional Accessories (Trunk Pop, etc., Opt. Part #775 required) NOTE: When the alarm is disarmed, press Button #3 and the trunk will open. - Page 12 arming only, after the unit is disarmed it reverts back to High Theft Off. Shock Sensitivity Reduction To reduce the on-board shock sensitivity to 50% (for this arming only), press Button #1 again within two seconds after arming. The system will chirp once (or flash the parking lights once if Silent Arming is activated). To shut off the Current Sensor (for this arming only) press Button #1 a second time after arming, the unit will chirp once.
