Preface and Hardware Architecture
1
2
This chapter is divided into the following sections,
Section 1.1: Introduction
Section 1.2: Hardware Architecture
Section 1.3: Box Connections
Section 1.4: Power Connection
Section 1.5: ADSL Port Connection
Section 1.6: Connector and Interface Description

1.1 Introduction

This document describes the new generation type integrated voice and data IVD, named IVD. The
IVD solution supports DSL and VoIP services and supplies high-speed Internet access and
voice/video streaming. It provides multicast, quality of service (QoS), security, SNMP-based EMS
(Element Management System), and user-friendly command line interface. With this powerful
management tool, both of the service providers and consumers can benefit from lower operating
costs and rapid deployment.
To meet the increasing demand for voice over IP services, the next generation network offers this
feasible functionality with the most cost effective architecture. IVD network is used to provide VoIP
service on traditional copper wire infrastructure. The type of service will be supported on NGN
(Next Generation Network) system architecture. IP DSLAM (IP based DSL Access Multiplexer) to
fast extend the coverage of xDSL services and to facilitate DSL deployment.
IVD is a remote type IP based VoIP Gateway provides toll quality voice communication in terms of
voice quality and reliability for the user. The type of service and application scenario is supported
on NGN system architecture and shown on following picture.
