Figure 4. 2W/4W Shdsl Ltu Menu Tree - ADTRAN Total Access SHDSL LTU Installation And Maintenance Practice

1. Unit Information
2. Provisioning
A
61182118L1-5B
SHDSL Version
Vendor List Number
Vendor Issue Number
Vendor Software Version
1. LTU
Unit Identification Code (CLEI)
Vendor ID
2. NTU
Vendor Model Number
Vendor Serial Number
Manufacture Date
PROM Check Sum
1. Line Card Service State
1. Unit Options
2. Cross-Connect Map
3. LT Mode Clock Source
4. External Port Alarms
5. NTU Auto-Provisioning
6. Circuit ID
7. Restore Factory Defaults
8. Upgrade Firmware
9. Local Management
10. Change Password
1. Interface Mode
2. Payload Rate (Kbps)
2. SHDSL Options
3. SNR Margin Alarm Threshold (dB)
4. Loop Attenuation Alarm Threshold (dB)
5. Outage Auto-Retrain
6. PM Thresholds
B

Figure 4. 2W/4W SHDSL LTU Menu Tree

Issue 2, July 2004
1. In Service
2. Out of Service - Unassigned
3. Out of Service - Maintenance
C
1. Internal Clock
2. G.703 RX Clock
3. SHDSL RX Clock
1. Disabled
2. Enabled
1. Disabled
2. Enabled
1. 2-wire
2. 4-wire
0. Disabled
1 - 15. Threshold in dB
0. Disabled
1 - 127. Threshold in dB
1. Disabled
2. Enabled
Loop 1 PM Thresholds
1. ES 15 Minute Alarm Threshold
2. SES 15 Minute Alarm Threshold
3. UAS 15 Minute Alarm Threshold
4. CVC 15 Minute Alarm Threshold
5. LOSWS 15 Minute Alarm Threshold
6. OS 15 Minute Alarm Threshold
Loop 2 PM Thresholds
7. ES 15 Minute Alarm Threshold
8. SES 15 Minute Alarm Threshold
9. UAS 15 Minute Alarm Threshold
10. CVC 15 Minute Alarm Threshold
11. LOSWS 15 Minute Alarm Threshold
12. OS 15 Minute Alarm Threshold
