Menuing System
The ADTRAN Total Access SCU provides a menuing
system for the Total Access shelf. All system-related
menus are controlled by the SCU. Each access module
has its own menu structure.
Menu Structure
The menu structure is a layered menu tree. Each menu
level consists of submenus and menu items. Some menu
items are restricted to certain user accounts. The
ADMIN account allows the user to change all provi-
sionable settings as well as network configuration
settings that are not accessible to READWRITE and
READONLY accounts. Examples include SNMP
provisioning, TL1 provisioning, Date/Time settings,
password administration, and software downloads. The
READWRITE account allows changes to standard
provisioning settings and the running of tests. The
READONLY account allows all provisioning settings,
alarms, and statistics to be viewed.
Shelf: 1
Unacknowledged Alarms:
Circuit ID: ORIGINAL SLOT 1 CARD
4
Slot: 1 Total Access System
1. Unit Information
2. Provisioning
3. Status
4. Test
5. Performance History
6. Terminal Mode
Selection:
?.

Figure 3. 2W/4W SHDSL LTU Main Menu

Issue 2, July 2004
Main Menu
After a successful login, access the
and select option 4,
Menu
choose the slot number of the desired 2W/4W SHDSL
LTU module. The 2W/4W SHDSL LTU
shown in Figure
Submenus
Submenus are elements that move the user down to the
next menu level. Menu items are elements which allow
the user to make changes to the current settings. There
are two different types of menu items: read-only and
read-write.
• A read-only menu item displays information that
cannot be changed, such as status information.
• A read-write menu item is displayed information
that when selected has options that can be changed,
such as the baud rate of the admin port.
Menu Tree
The menu tree in
provisioning, performance, and test access point in the
SHDSL menu system.
Main Menu
System Help
Total Access Main
Access Modules
Main Menu
3.
Figure 4 illustrates the path to every
10/21/03 16:29
Terminal Mode: Local
61182118L1-5B
. Then
is
