Light Check - ASA Electronics iN-Command NCS40T Installation And Operation Manual

NCS40T

• Light Check

To perform the Light Check, press the Light Check icon on the home page. The user will be prompeted with two Travel Lock Engaged popups.
To proceed, make sure it is safe to proceed, then press Yes on the first popup. The second popup will appear, press Yes again. Once in the Light
Check page, the Travel Lock Counter will start counting down from 120 seconds. Press either the Left Turn, Right Turn, Running or Brake light bar.
The light group being checked will be highlighted with a green outline around the bar. The light group will stay on until the next light bar is pressed,
leaving the Light Check page, or the Travel Lock timer runs out. If the Travel Lock timer runs out before all lights have been checked, press on
any of the light group bars to start the process over. The Travel Lock popups will appear again also.
21
