TELESCOPIC POLE SERIES
FOR USE ONLY WITH THE 56V LITHIUM-ION
TELESCOPIC POWER POLE PPX1000
OPERATOR'S MANUAL
HEDGE TRIMMER ATTACHMENT
MODEL NUMBER PTX5100
WARNING: To reduce the risk of injury, the user must read and understand the
Operator's Manual before using this product. Save these instructions for future reference.
MNL_EGO_PTX5100_AV01.01_210329
