Summary of Contents for Buhler Farm king FK329
-
Page 2: Table Of Contents
#1080 Snowblower TABLE OF CONTENTS DESCRIPTION PAGE Warranty ...1 Safety Instructions & Safety Sign Locations ...2 Operating Instructions ...3 Assembly Instructions ...5 #1080 Farm King Snowblower Drawings ...7 #1080Farm King Snowblower Parts List ...10 #1080 Farm King Snowblower PTO Drawing...14 #1080 Farm King Snowblower PTO Parts List...15 Shipping Bundles ...16... -
Page 3: Warranty Policy
#1080 Snowblower WARRANTY POLICY Buhler Manufacturing products are warranted for a period of twelve (12) months (90 days for commercial application) from original date of purchase, by original purchaser, to be free from defects in material and workmanship under correct, normal agricultural use and proper applications. -
Page 4: Safety Instructions & Safety Sign Locations
#1080 Snowblower SNOWBLOWERS This manual is for model #1080 snowblowers with a combination three point and quick coupler hitch. All model #1080 snowblowers use an open gear drive. The standard model is a push type, which will mount to a tractor with 1000 rpm PTO only. This model uses a chain drive reducer in the welded gearbox assembly, which runs in an oil bath. -
Page 5: Operating Instructions
OPERATING INSTRUCTIONS 1. Do not operate the blower in the fully raised position. The three-point hitch on some tractors raises high enough to cause the PTO shaft to bind. This can cause damage to the PTO shaft and/or to the hitch and pins. 2. - Page 6 OPERATING INSTRUCTIONS – cont’d. 10. Lubrication: The spout clamps and rings should be periodically lubricated with gun grease. This is particularly important on the truckloader spout which turns harder than the standard spout due to the length and weight. PTO shaft universal joints and splined slide should be greased daily. Regularly oiling the chain will significantly increase the life of the chain.
-
Page 7: Assembly Instructions
ASSEMBLY INSTRUCTIONS 1. Hitch Assembly: With lower hitch tubes (#3) turned as shown in drawing, slide them into the sleeves welded to the main body. These tubes are adjustable to two different positions. The correct position for each individual tractor will be determined when mounting the snowblower on the tractor (see Section 4). - Page 8 ASSEMBLY INSTRUCTIONS - Cont'd. 4. Mounting blower on Tractor: Mount the blower on a tractor with a category 2 or 3 standard hitch or a category 3 quick hitch. The hitch has two holes both at the top of the hitch and at each lift arm.
-
Page 9: 1080 Farm King Snowblower Drawings
#1080 Snowblower #1080 SNOWBLOWER - 7 -... - Page 10 #1080 Snowblower - 8 -...
- Page 11 #1080 Snowblower - 9 -...
-
Page 12: 1080Farm King Snowblower Parts List
WHEN ORDERING PARTS Always give your dealer the Model, Color, and Serial Number of your machine to assist him in ordering and obtaining the correct parts. Use the exploded view and tabular listing of the area of interest to exactly identify the required part. Item # Part # 906491... - Page 13 81676 5/8'' Hex Nut (pl) 81549 5/16'' X 3/4'' Hex Bolt (pl) 81569 5/16'' Lock Washer (pl) 81568 5/16'' Hex Nut (pl) 965216 Auger (15'' O.D. X 107 3/8''Lg) 902902 4-Blade Fan Weldt 965294 Jack Stand Pin F9231 Standard PTO (1 3/8'' X 21 spline) F9232 Optional PTO (1 3/4'' X 20 spline) F9233...
- Page 14 965305 Spout Link - 8 3/4'' 965238 Cylinder Arm 965239 Hose Clamp 81620 1/2'' X 1 1/4'' Hex Bolt (pl) 812364 1/2'' Lock Nut (pl) 965266 CAT. 2-3 Top Link Pin Bushing 965267 CAT. 2-3 Lift Arm Bushing 965268 Fan Housing Liner 967431 3/8'' X 1'' Flat Head Bolt (pl) 905609...
- Page 15 115371 3/8'' x 156'' Hose w/fittings 115369 3/8 x 156 Hose 1/2 MNPT x 9/16 SWFJIC 811918 Elbow 90deg 9/16 SWMORB x 9/16 MJIC 886786 Elbow 90deg 1/4'' MNPT x 9/16'' MJIC 902127 1/2'' x 1 3/4'' Gear Key (540 RPM) 936402 PTO Safety Chain 967433...
-
Page 16: 1080 Farm King Snowblower Pto Drawing
#1080 Snowblower #1080 SNOWBLOWER PTO - 14 -... -
Page 17: 1080 Farm King Snowblower Pto Parts List
108'' SNOWBLOWER PTO SHAFT PARTS LIST Item # Part # Description F9231 Standard Shaft (21 Spline, 1 3/8'') - 1000 RPM F9232 Optional Shaft (20 Spline, 1 3/4'') - 1000 RPM F9233 540 RPM Shaft (6 Spline, 1 3/8'') 936413 Standard Shear Assembly (21 Spl, 1 3/8'') 936422 Shear Hub Only (21 Spl, 1 3/8'') -
Page 18: Shipping Bundles
#1080 SNOWBLOWER BUNDLES QUANTITY BUNDLE NO. 1000 RPM WITH STANDARD SPOUT – Y1080C F9244 F9241 F0198 F0560 F9231 1000 RPM WITH TRUCKLOADER SPOUT – Y1080CT F9244 F9243 F0198 F9118 F9231 540 RPM WITH STANDARD SPOUT – Y1080D F9244 F9241 F0200 F0560 F9233 540 RPM WITH TRUCKLOADER SPOUT –... - Page 19 SK, Regina (306) 781-2300 ON, Woodstock (519) 539-0435 ON, Jasper (613) 283-1758 QC, Dorion (450) 455-4840 Buhler Manufacturing “ a partnership” 301 Mountain Street S. Morden MB. R6M 1X7 Ph.: (204) 822-4467 Fax: (204) 822-6348 www.buhler.com U.S. WAREHOUSES ND, Bismarck...
