Summary of Contents for Buhler Allied FK332
-
Page 2: Table Of Contents
108” Allied Snowblower TABLE OF CONTENTS DESCRIPTION PAGE Warranty ...1 Safety Instructions & Safety Sign Locations ...2 Operating Instructions ...3 Assembly Instructions ...5 108” Allied Snowblower Drawings...7 108” Snowblower Gearbox & Spouts Drawing ...9 108” Allied Snowblower Parts List...10 108” Allied Snowblower PTO Drawing ...14 108”... -
Page 3: Warranty Policy
108” Allied Snowblower WARRANTY POLICY Buhler Manufacturing products are warranted for a period of twelve (12) months (90 days for commercial application) from original date of purchase, by original purchaser, to be free from defects in material and workmanship under correct, normal agricultural use and proper applications. -
Page 4: Safety Instructions & Safety Sign Locations
108” Allied Snowblower SNOWBLOWERS This manual is for model #1080 snowblowers with a combination three point and quick coupler hitch. All model #1080 snowblowers use an open gear drive. The standard model is a push type which will mount to a tractor with 1000 rpm PTO only. This model uses a chain drive reducer in the welded gearbox assembly which runs in an oil bath. -
Page 5: Operating Instructions
OPERATING INSTRUCTIONS 1. Do not operate the blower in the fully raised position. The three-point hitch on some tractors raises high enough to cause the PTO shaft to bind. This can cause damage to the PTO shaft and/or to the hitch and pins. 2. - Page 6 OPERATING INSTRUCTIONS – cont’d. 10. Lubrication: The spout clamps and rings should be periodically lubricated with gun grease. This is particularly important on the truckloader spout which turns harder than the standard spout due to the length and weight. PTO shaft universal joints and splined slide should be greased daily. Regularly oiling the chain will significantly increase the life of the chain.
-
Page 7: Assembly Instructions
ASSEMBLY INSTRUCTIONS 1. Hitch Assembly: With lower hitch tubes (#3) turned as shown in drawing, slide them into the sleeves welded to the main body. These tubes are adjustable to two different positions. The correct position for each individual tractor will be determined when mounting the snowblower on the tractor (see section 4). - Page 8 ASSEMBLY INSTRUCTIONS - Cont'd. 4. Mounting Blower on Tractor: Mount the blower on a tractor with a category 2 or 3 standard hitch or a category 3 quick hitch. The hitch as two holes both at the top of the hitch and at each lift arm.
-
Page 9: 108" Allied Snowblower Drawings
108” Allied Snowblower 108” SNOWBLOWER - 7 -... - Page 10 108” Allied Snowblower - 8 -...
-
Page 11: 108" Snowblower Gearbox & Spouts Drawing
108” Allied Snowblower 108” SNOWBLOWER GEARBOX & SPOUTS - 9 -... -
Page 12: 108" Allied Snowblower Parts List
WHEN ORDERING PARTS Always give your dealer the Model, Color and Serial Number of your machine to assist him in ordering and obtaining the correct parts. Use the exploded view and tabular listing of the area of interest to exactly identify the required part. Item # Part # 906491A... - Page 13 81549 5/16'' X 3/4'' Hex Bolt (pl) 81569 5/16'' Lock Washer (pl) 81568 5/16'' Hex Nut (pl) 965216 Auger (15'' O.D. X 107 3/8''lg) 902902 4-Blade Fan Weldt 965294A Jack Stand Pin F9231 Standard PTO (1 3/8'' X 21 spline) F9232 Optional PTO (1 3/4'' X 20 spline) F9233...
- Page 14 965238 Cylinder Arm 965239 Hose Clamp 81620 1/2'' X 1 1/4'' Hex Bolt (pl) 812364 1/2'' Lock Nut (pl) 965266 CAT. 2-3 Top Link Pin Bushing 965267 CAT. 2-3 Lift Arm Bushing 965268 Fan Housing Liner 967431 3/8'' X 1'' Flat Head Bolt (pl) 905609 5/8'' X 2 1/4'' Flat Head Bolt (pl) 810149...
- Page 15 115371 3/8'' X 156'' Hose w/fittings 115369 3/8 X 156 Hose 1/2 MNPT X 9/16 SWFJIC 811918 Elbow 90deg 9/16 SWMORB X 9/16 MJIC 886786 Elbow 90deg 1/4'' MNPT X 9/16'' MJIC 902127 1/2'' x 1 3/4'' Gear Key (540 RPM) 936402 PTO Safety Chain 967433...
-
Page 16: 108" Allied Snowblower Pto Drawing
108” Allied Snowblower 108” ALLIED SNOWBLOWER PTO - 14 -... -
Page 17: 108" Allied Snowblower Pto Parts Lists
108'' SNOWBLOWER PTO SHAFT PARTS LIST Item # Part # Description F9231 Standard Shaft (21 Spline, 1 3/8'') - 1000 RPM F9232 Optional Shaft (20 Spline, 1 3/4'') - 1000 RPM F9233 540 RPM Shaft (6 Spline, 1 3/8'') 936413 Standard Shear Assembly (21 Spl, 1 3/8'') 936422 Shear Hub Only (21 Spl, 1 3/8'') -
Page 18: Shipping Bundles
ALLIED SNOWBLOWER BUNDLES QUANTITY BUNDLE NO. 1000 RPM WITH STANDARD SPOUT – YC1080C FX9244 F9241 FX0199 F0560 F9231 1000 RPM WITH TRUCKLOADER SPOUT – YC1080CT FX9244 F9243 FX0199 F9118 F9231 540 RPM WITH STANDARD SPOUT – YC1080D FX9244 F9241 FX0201 F0560 F9233 540 RPM WITH TRUCKLOADER SPOUT –... - Page 19 SK, Regina (306) 781-2300 ON, Woodstock (519) 539-0435 ON, Jasper (613) 283-1758 QC, Dorion (450) 455-4840 Buhler Manufacturing “ a partnership” 301 Mountain Street S. Morden MB. R6M 1X7 Ph.: (204) 822-4467 Fax: (204) 822-6348 www.buhler.com U.S. WAREHOUSES ND, Bismarck...
