Summary of Contents for Nature Power 37750
- Page 1 V1.1-M 13Apri2020 User Manual WARNING Read carefully and understand all ASSEMBLY AND OPERATION，INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety，precautions may result in serious personal injury. Item #37750 SAVE THESE INSTRUCTIONS...
- Page 2 T an you for c oosin a Nature Po er Pro uct This product is designed for certain applications only. he distributor cannot be responsible for issues arising from modification. We strongly recommend this product not be modified and/or used for any application other than that for which it was designed. If you have a question relative to a particular application, o not use the product until you have first contacted the distributor to determine if it can or should be performed on the product.
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS. maintenance or cleaning. Turning off 1. SAVE THESE INSTRUCTIONS. This manual contains important safety controls will not reduce this risk. and operating instructions for power 7. For the most effective use, place the inverter 750W .This manual will show power inverter on a flat surface. - Page 4 • High-speed cooling fan • ON/OFF rocker switch To keep the inverter cool, the fan turn on • LED indicator depend on the load on the inverter or Green indicates Power ON temperature in the inverter. The fans do Red indicates Overload/Interruption not run when the inverter is turned off.
- Page 5 Page of 12...
- Page 6 P RA ING IN 5. Make sure the device to be operated . Connect the inverter (see Connecting is turned OFF. Inverter Cables section). 6. Plug the device into the inverter’s . Switch the inverter’s ON/OFF switch to AC outlet. the ON (I) position.
-
Page 7: Power Source
NOTE: If more than one device is to be damage the inverter and/or device. If powered, start one device at a time, to you are using the inverter to operate avoid a power surge and overloading a rechargeable device, monitor the the inverter. -
Page 8: Led Indicator And Shutdown Protection
LED INDICATOR AND SHUTDOWN PROTECTION The Green LED lights automatically The continuous load demand from the when the inverter is plugged into a 12 volt equipment or device being operated DC power source and is turned on. The exceeds the continuous load rating of Red LED lights, the alarm sounds and the the inverter. -
Page 9: Maintenance And Storage Instructions
MAINTENANCE AND STORAGE INSTRUCTIONS 1. Before each use, ensure that all of the 4. Servicing does not require opening the inverter’s components are in place and unit, as there are no user-serviceable in good working condition. parts. All servicing should be performed 2. -
Page 10: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE REASON/SOLUTION Red LED is on, Poor contact at terminals. Check for poor connection to alarm sounds, battery or power supply. Make and/or inverter sure connection points are clean. does not function. Rock clamps back and forth for a better connection. -
Page 11: Specifications
SPECIFICATIONS Nominal input voltage ................. 12.8-13.2 VDC Nominal output voltage ...................115±10 VAC Output frequency ..................... 60 Hz±3 Hz Operating input voltage ................10.0-15.0 VDC Continuous output power ................Up to 750 W Surge output power ....................1500 W Waveform ....................Typical Effciency (at nominal input voltage) ............. -
Page 12: Limited Warranty
If defective part or unit should be returned, a Return Authorization Number must be issued by Nature Power and the defective part or unit should be returned to the authorized location at the purchasers’ expense. A dated proof of purchase is required to receive warranty service.
