Nature Power 37001 User Manual

1000 watt power inverter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
V1.1-M 13Apri2020
100
User Manual
WARNING Read carefully and understand all ASSEMBLY AND
OPERATION，INSTRUCTIONS before operating. Failure to follow the safety
rules and other basic safety，precautions may result in serious personal injury.
Item #37001
SAVE THESE INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 37001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nature Power 37001

Summary of Contents for Nature Power 37001

  • Page 1 V1.1-M 13Apri2020 User Manual WARNING Read carefully and understand all ASSEMBLY AND OPERATION，INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety，precautions may result in serious personal injury. Item #37001 SAVE THESE INSTRUCTIONS...
  • Page 2 T an you for c oosin a Nature Po er Pro uct This product is designed for certain applications only. The distributor cannot be responsible for issues arising from modification. We strongly recommend this product not be modified and/or used for any application other than that for which it was designed. If you have a question relative to a particular application, o not use the product until you have first contacted the distributor to determine if it can or should be performed on the product.

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS. 1. SAVE THESE INSTRUCTIONS. maintenance or cleaning. Turning off This manual contains important safety controls will not reduce this risk. and operating instructions for power 7. For the most effective use, place the inverter 1000W .This manual will show power inverter on a flat surface.

  • Page 4: Connecting Inverter Cables

    FEATURES • High-speed cooling fan • ON/OFF rocker switch To keep the inverter cool, the fan turn on • LED indicator depend on temperature in the inverter. Green indicates Power ON The fans do not run when the inverter Red indicates Overload/Interruption is turned off.
  • Page 5 6. Attach the other end of the wire to a 2. From the POSITIVE (RED) and the properly grounded location: NEGATIVE (BLACK) terminals, remove Vehicle: Connect to the chassis, unpainted 3. Place the POSITIVE (RED) ring frame part, or engine block of the vehicle. connector onto the POSITIVE Fixed location: Connect to a ground rod (RED) inverter terminal.
  • Page 6 OPERATING INSTRUCTIONS “beep”. This is normal.) 1. Connect the inverter (see Connecting Inverter Cables section. 5. Make sure the device to be operated is turned OFF. 2. Switch the inverter’s ON/OFF switch to the ON (I) position. 6. Plug the device into the inverter’s AC outlet.

  • Page 7: Power Source

    NOTE: If more than one device is to be damage the inverter and/or device. If powered, start one device at a time, to you are using the inverter to operate avoid a power surge and overloading a rechargeable device, monitor the the inverter.

  • Page 8: Led Indicator And Shutdown Protection

    LED INDICATOR AND SHUTDOWN PROTECTION The Green LED lights automatically when The continuous load demand from the the inverter is plugged into a 12 volt equipment or device being operated DC power source and is turned on. The exceeds the continuous load rating of Red LED lights, the alarm sounds and the inverter.

  • Page 9: If The Inverter's Fuse Blows

    IF THE INVERTER’S FUSE BLOWS polarity or a short circuit within the device which should not have to be replaced or equipment being operated. under normal operating conditions. A If a fuse does blow, take the inverter to blown fuse is usually caused by reverse MAINTENANCE AND STORAGE INSTRUCTIONS 1.

  • Page 10: Troubleshooting

    TROUBLESHOOTING PROBLEM POSSIBLE CAUSE REASON/SOLUTION Low or no output Poor contact at terminals Disconnect and reconnect the 12V voltage. connections. OVP/OLP. Using incorrect type of voltmeter Use a true RMS reading meter. to test output voltage. Red LED is lit. The battery voltage is below Recharge or replace the battery.

  • Page 11: Specifications

    SPECIFICATIONS Nominal input voltage ..................12.8-13.2 VDC Nominal output voltage ................115±10% VAC Output frequency ....................60±3 Hz Operating input voltage ................10.0-15.0 VDC Continuous output power ................Up to 1000 W Surge output power ....................2000 W Waveform ..................... Modified sine wave Efficiency (typical) .......................

  • Page 12: Limited Warranty

    If defective part or unit should be returned, a Return Authorization Number must be issued by Nature Power and the defective part or unit should be returned to the authorized location at the purchasers’ expense. A dated proof of purchase is required to receive warranty service.
