Daktronics MS-2013 Display Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MS-2013 Portable
LED Scoreboard
Display Manual
Rev 10 – 15 June 2016
ED-13145
201 Daktronics Drive PO Box 5128 Brookings, SD 57006-5128
Tel: 1-800-DAKTRONICS (1-800-325-8766) Fax: 605-697-4746
www.daktronics.com/support

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS-2013 and is the answer not in the manual?

Questions and answers

Related Manuals for Daktronics MS-2013

Summary of Contents for Daktronics MS-2013

  • Page 1 MS-2013 Portable LED Scoreboard Display Manual Rev 10 – 15 June 2016 ED-13145 201 Daktronics Drive PO Box 5128 Brookings, SD 57006-5128 Tel: 1-800-DAKTRONICS (1-800-325-8766) Fax: 605-697-4746 www.daktronics.com/support...
  • Page 3 – graphic, electronic, or mechanical, including photocopying, taping, or information storage and retrieval systems – without written permission of the publisher. ® ® All Sport and PanaView are trademarks of Daktronics, Inc. Other trademarks used in this manual are the property of their respective owners.

  • Page 5: Table Of Contents

    Table of Contents Section 1: Introduction ......................... 1 Specifications Label......................... 1 Scoreboard Controllers ......................1 Resources ..........................2 Daktronics Nomenclature ...................... 2 Product Safety Approval......................2 Section 2: Specifications ......................3 Section 3: Mechanical Installation ....................5 Cart Assembly ......................... 5 Adjusting the Cart ........................
  • Page 6 Section 7: Daktronics Exchange and Repair & Return Programs .......... 25 Exchange Program ........................ 25 Before Contacting Daktronics ..................25 Repair & Return Program ....................26 Shipping Address ......................26 Daktronics Warranty and Limitation of Liability ............. 26 Appendix A: Reference Drawings ....................

  • Page 7: Introduction

    Figure 1: Specifications Label Please have the assembly number, model number, and the date manufactured on hand when calling Daktronics customer service to ensure the request is serviced as quickly as possible. Knowing the facility name and/or job number will also be helpful.

  • Page 8: Resources

    Reference Drawing: System Riser Diagram ..................C-1007804 Daktronics identifies manuals by the DD or ED number located on the cover page of each manual. For example, this manual would be referred to as ED-13145. Daktronics Nomenclature Most components within this display carry a white label that lists the part number of the unit.

  • Page 9: Specifications

    Section 2: Specifications The table below lists all of the mechanical specifications, circuit specifications, and power requirements for the MS 2013. Scoreboard Only: Dimensions (Height, Width, Depth) 2'-10" H x 4'-4" W x 8" D (864 mm, 1.32 m, 203 mm) With Cart (minimized for transport/storage): 3'-4"...

  • Page 11: Mechanical Installation

    Some assembly is required, however, for certain scoreboard options. Cart Assembly Reference Drawings: Mechanical Specifications, MS-2013 ..............A-159886 Cart Assembly ....................... A-159889 The display cart (Figure 4) comes standard with two wheels, but may use four if ordered. Cart assembly requires the following pieces of hardware: ...

  • Page 12: Optional Equipment Installation

    Ad Panel A custom advertising/school logo panel may be added to the MS-2013. Threaded inserts in the top of the scoreboard cabinet allow attachment using only three screws. The 12" H x 52" W (305 mm, 1.32 m) aluminum panel runs the full width of the scoreboard. Drawing A- 160057 in Appendix A illustrates the ad panel installation.

  • Page 13: Electrical Operation

    Section 4: Electrical Operation The MS-2013 can be powered by two different electrical systems: a standard 120 VAC power source and/or enclosed lead-acid batteries. Power & Signal Access Power and control connections for the MS-2013 are located in a compartment on the rear of the scoreboard (Figure 5).

  • Page 14: Signal

    Signal Reference Drawings: System Riser Diagrams- MS-2013-11 ..............A-160237 The MS-2013 can receive control signal three different ways, described below. Refer also to Drawing A-160237 in Appendix A for diagrams of each of these control setups.  Setup 1 (Standard): A wireless RC-100 handheld controller communicates with a radio base station installed inside the scoreboard.

  • Page 15: Base Station & Radio Receiver Installation

    Radio Receiver Installation, MS-2013 ..............A-160015 Base Station: Outdoor Installation ................. A-236394 System Riser Diagram: RC-100- MS-2013 ............A-244926 Installation Drawing; Outdoor Scbd Gen VI Radio Receiver ....... A-1109181 The RC-100 base station and All Sport radio receiver are typically held in place with adhesive-backed, hook-and-loop fastener strips, and when ordered as original equipment may already be installed.

  • Page 16: Power-On Self-Test (Post)

    Power-On Self-Test (POST) The scoreboard performs a self-test each time that power is turned on and the control console is powered off or not attached to the scoreboard. If the control console is attached and powered on, the self-test does not run, and data from the control console is displayed on the scoreboard after a brief period of time.

  • Page 17: Battery Care & Charging

    Section 5: Battery Care & Charging This section describes care and operation of the MS-2013 on-board battery charging system. On-Board Charger Reference Drawing: Electrical Specifications. MS-2013 ................ A-159887 On a full charge, the two internal batteries provide enough power for approximately 14 hours of normal operation.
  • Page 18 The ChargePro 28210 charger, shown in Figure 8, is a 2 bank, 10 A, 12/24 VDC output charger with an input of 120 VAC. It is microprocessor controlled and has a maintenance mode that will keep the batteries fully charged. The charger is fully automatic and can be connected to the twin 12 V lead-acid batteries indefinitely without risk of overcharging.

  • Page 19: Operation

    If the in-line 10 A, 32 VDC fuse in either cable blows due to improper connection to a battery, replace the fuse with an identical 10 A fuse only (Daktronics part # F-1006). Never replace a blown fuse with a higher-value fuse.

  • Page 20: Charger Troubleshooting Table

    Charger Troubleshooting Table Problem Cause Solution It seems to take a long time The charger has overheated due Consider moving the display to to recharge the batteries in to poor air circulation and has a shaded location. hot weather. reduced its output. Load test the battery and One or more defective or replace if necessary (see...

  • Page 21: Radio Interference

    Some of the safety considerations are not applicable to the sealed batteries provided with the MS-2013 as those batteries are self-contained and cannot be opened, and they are safer than automotive batteries that require servicing. Exercise caution, however, when working with any lead-acid battery.

  • Page 22: Dc Connection Precautions

    DC Connection Precautions Check the polarity markings on the battery. Attach the positive ring terminals (red or white wires with fuse) from each cable on the charger to the positive (+) terminals of the batteries. Attach the negative ring terminals (black wires) from each cable on the charger to the negative (-) terminals of the batteries.

  • Page 23: Scoreboard Troubleshooting

    If a problem occurs that is not listed or that cannot be resolved using the solutions in the following table, contact Daktronics using the information provided in Section 7. Problem...
  • Page 24 Problem Possible Cause Solution/Items to Check Check that the green POWER and amber RADIO IN RANGE indicators on the radio receiver in the scoreboard light up when the control console is powered on. Keep the console between 20-30' (6-9 m) from the scoreboard.

  • Page 25: Component Location & Access

    Reference Drawing: Electrical Specifications, MS-2013 ................ A-159887 In the MS-2013, the entire back panel is hinged on the right side (as viewed from the rear). To gain access to the internal scoreboard components, simply remove the three screws securing the back panel to the scoreboard cabinet, and swing it open. Drawing A-159887 in Appendix A illustrates the back panel open and all of the internal components exposed.

  • Page 26: Segmentation & Digit Designation

    Reference Drawings: Segmentation, 7 Segment Bar Digit ................ A-38532 Electrical Specifications, MS-2013 ................ A-159887 In each digit, certain LEDs always go on and off together. These groups of LEDs are called segments. Drawing A-38532 in Appendix A details which connector pin is wired to each digit segment and the wiring color code used throughout the scoreboard.

  • Page 27: Replacing A Driver

    When troubleshooting driver problems, several LEDs provide diagnostic information. The number of LEDs and their function depends on the driver type. Note: While it is necessary to have the scoreboard powered on to check the LED indicators, always disconnect scoreboard power before servicing. 16-Column “Gyrus”...

  • Page 28: Setting The Driver Address

    As the batteries age, they may lose capacity to sufficiently operate the scoreboard, even on a full charge. When replacement becomes necessary, Daktronics recommends the same brand battery installed as original equipment. Similar batteries may be used as long as they meet the specifications for the scoreboard.

  • Page 29: Horn

    Horn Reference Drawing: Electrical Specifications, MS-2013 ................ A-159887 A 12 V buzzer horn is mounted in the upper-left corner of the front face panel (as viewed from the front). Drawing A-159887 in Appendix A shows the horn location from the front as well as when accessing internal components from the rear.

  • Page 31: Daktronics Exchange And Repair & Return Programs

    The Daktronics Exchange Program is a service for quickly replacing key components in need of repair. If a component fails, Daktronics sends a replacement part to the customer who, in turn, returns the failed component to Daktronics. This decreases equipment downtime.

  • Page 32: Repair & Return Program

    Repair & Return Program For items not subject to exchange, Daktronics offers a Repair & Return Program. To send a part for repair, follow these steps: Call or fax Daktronics Customer Service: Refer to the appropriate market phone number in the chart on the previous page.

  • Page 33: Appendix A: Reference Drawings

    Electrical Specifications, MS-2013 ................... A-159887 Cart Assembly, MS-2013 ......................A-159889 Caption Options, MS-2013 ....................... A-159890 Battery Service, MS-2013 ......................A-159891 Radio Receiver Installation- MS-2013 ..................A-160015 Ad Panel Installation, MS-2013 ....................A-160057 Cover Installation- MS-2013 ..................... A-160060 System Riser Diagrams- MS-2013-11 ..................A-160237 Base Station: Outdoor Installation ....................
  • Page 38 THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DAKTRONICS, INC. DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESS WRITTEN CONSENT OF DAKTRONICS, INC. COPYRIGHT 2015 DAKTRONICS, INC. SCOREBOARDS ELECTRICAL SPECIFICATIONS- MS-2013 A VANBEMMEL 11 DEC 01...
  • Page 39 THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESS WRITTEN CONSENT OF DAKTRONICS, INC. OR ITS WHOLLY OWNED SUBSIDIARIES. COPYRIGHT 2016 DAKTRONICS, INC. (USA) OUTDOOR LED DIGIT SCOREBOARDS...
  • Page 40 THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DAKTRONICS, INC. DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESS WRITTEN CONSENT OF DAKTRONICS, INC. COPYRIGHT 2014 DAKTRONICS, INC. OUTDOOR LED DIGIT SCOREBOARDS CAPTION OPTIONS- MS-2013 A VANBEMMEL...
  • Page 41 THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DAKTRONICS, INC. DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESS WRITTEN CONSENT OF DAKTRONICS, INC. COPYRIGHT 2015 DAKTRONICS, INC. SCOREBOARDS BATTERY SERVICE- MS-2013 A VANBEMMEL 11 DEC 01...
  • Page 42 IF THERE ARE TO BE MULTIPLE SCOREBOARD RECEIVERS AND MULTIPLE CONTROL CONSOLES OPERATING IN THE AREA, REFER TO RADIO INSTALLATION MANUAL(S) TO CHANGE THE CHANNEL NUMBER ON THE RECEIVER PRIOR TO INSTALLING. REMOVE THE THREE SCREWS SECURING THE BACK OF THE MS-2013, AND SWING IT OPEN. RADIO GYRUS VIEW...
  • Page 45 DAKTRONICS HOME DAKTRONICS GUEST PERIOD HOME DAKTRONICS GUEST PERIOD...
  • Page 46 EXTERNAL ANTENNA ON OUTSIDE FACE OF SCOREBOARD. ANTENNA PART NUMBER AND SIZE WILL VARY. TX RX TX RX CL / RS232 RANGE...
  • Page 47 HOME GUEST DAKTRONICS PERIOD...
  • Page 49 THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS DAKTRONICS, INC. DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT REPRODUCE BY ANY MEANS WITHOUT THE EXPRESSED WRITTEN CONSENT OF DAKTRONICS, INC. COPYRIGHT 2012 DAKTRONICS, INC. ALL SPORT RADIO ADDED GYRUS VIEW DATE: INSTALLATION DRAWING;...
  • Page 50 DAKTRONICS, INC. ON = OK DRAWING ARE CONFIDENTIAL AND PROPIETARY. DO NOT BROOKINGS, SD 57006 REPRODUCE BY ANY MEANS WITHOUT THE EXPRESSED WRITTEN CONSENT OF DAKTRONICS INC. OFF = Disconnected Copyright © 2015 Daktronics Inc. DO NOT SCALE DRAWING PROJECT TITLE SPECIFICATIONS;...
  • Page 51 Appendix B: Daktronics Warranty and Limitation of Liability Daktronics Warranty and Limitation of Liability...
  • Page 53 DAKTRONICS WARRANTY & LIMITATION OF LIABILITY This Warranty and Limitation of Liability (the “Warranty”) sets forth the warranty provided by Daktronics with respect to the Equipment. By accepting delivery of the Equipment, Purchaser and End User agree to be bound by and accept these terms and conditions. Unless otherwise defined herein, all terms within the Warranty shall have the same meaning and definition as provided elsewhere in the Agreement.
  • Page 54 In no event shall Daktronics be liable for loss, damage, or injury of any kind or nature arising out of or in connection with this Warranty in excess of the Purchase Price of the Equipment. The End User’s remedy in any dispute under this Warranty shall be ultimately limited to the Purchase Price of the Equipment to the extent the Purchase Price has been paid.
