Chapter 3: BIOS Setup
IDE Configuration
This section is used to configure the SATA drives.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Advanced
IDE Configuration
Serial-ATA (SATA) [Enabled]
SATA Speed Support [Gen2]
SATA Mode [AHCI Mode]
Serial-ATA Port 0 [Enabled]
SATA Port0 HotPlug [Disabled]
Serial-ATA Port 1 [Enabled]
SATA Port1 HotPlug [Disabled]
SATA Port0
Not Present
SATA Port1
Not Present
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Serial-ATA (SATA)
Enables or disables the SATA device.
SATA Speed Support
Configures the SATA controller to Gen1 or Gen2 speed.
Copyright © 2014 NEXCOM International Co., Ltd. All Rights Reserved.
Configure SATA As
Configures the SATA as IDE, AHCI or RAID mode.
IDE
Enable / Disable Serial ATA
RAID
AHCI
→←: Select Screen
↑↓: Select Item
Serial-ATA Port 0 and Serial-ATA Port 1
Enter: Select
+/-: Change Opt.
Enables or disables SATA port 0 and SATA port 1.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
SATA Port1 Hotplug and SATA Port2 Hotplug
F4: Save & Exit
ESC: Exit
Enables or disables hotplug support on SATA port 1 and SATA port 2.
40
This option configures the Serial ATA drives as Parallel ATA
physical storage device.
This option allows you to create RAID or Intel Matrix Storage
configuration on Serial ATA devices.
This option configures the Serial ATA drives to use AHCI
(Advanced Host Controller Interface). AHCI allows the storage
driver to enable the advanced Serial ATA features which will
increase storage performance.
