Chapter 1: Product Introduction

Knowing Your EBC 355

Top View

+12V DC Input
Reset
Power
Copyright © 2014 NEXCOM International Co., Ltd. All Rights Reserved.
JP2: SMBus
JP3: LCD Power Select
LVDS Panel Inverter
PWM/CCFL
Select System FAN
AT/ATX Select HDMI
VGA
SATA SATA Power
SATA SATA DOM
LVDS A LVDS B DOM Power
USB 2/3 USB 0/1 LAN1 LAN2
4
Power/HDD LED
PS/2 K/B Mouse
GPIO
COM2
COM3
J6: COM1, J7: COM4
Speaker-out
Line-out
Mic-in
