Chapter 2: Jumpers and Connectors

Mic-in Connector

Connector type: 1x4 4-pin header, 2.0mm pitch
Connector location: JP9
1 4
Pin Definition
1 MIC1_L
2 GND
3 MIC_JD
4 MIC1_R
Copyright © 2014 NEXCOM International Co., Ltd. All Rights Reserved.

Line-out Connector

Connector type: 1x4 4-pin header, 2.0mm pitch
Connector location: JP10
1 4
Pin Definition
1 LOUT_L
2 GND
3 LOUT_JD
4 LOUT_R
21
