Chapter 2: Jumpers and Connectors

RTC Clear Select

Connector type: 2x2 4-pin DIP switch
Connector location: SW1
1 2
Pin Definition
1 ON Clear CMOS
2 ON Clear ME
Copyright © 2014 NEXCOM International Co., Ltd. All Rights Reserved.

System Reset

Connector type: 1x2 2-pin header, 2.0mm pitch
Connector location: JP11
1 2
Pin Definition
1 Reset
2 GND
16
