Textron EZGO TXT Valor Service & Parts Manual page 94

FUEL SYSTEM
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
31 606969
32
33
34 11391G4
35 604597
36
37 602061
38 00114G6
39
40 606310
41 10570G11
42
43
44 606071
Page N-3
1 2 3 4 5
FUEL HOSE, .25" I.D. X .5" O.D. X 8" LG .......................................................
HOSE CLAMP, .25" .........................................................................................
FUEL HOSE, 26" LG .......................................................................................
FUEL PUMP ....................................................................................................
HEX WASHER HEAD BOLT, 1/4" - 10 X 3/4" LG ............................................
CANISTER BRACKET (CARB ONLY).............................................................
RIVET (SS), 3/16" X .70" LG (CARB ONLY) ...................................................
CARBON CANISTER (CARB ONLY) ..............................................................
653637 Service Parts Manual
DESCRIPTION QTY.
1
2
1
1
2
1
2
1
