Textron EZGO TXT Valor Service & Parts Manual page 15

When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
1 606083
2 606005
3 73876G01
4 606421
5 450452
6 606283
7 606284
8 603890
9 606264
10 606262
11 606074
12 606256
13
14 608527
15
16
17 17618G1
18
19 632936
1 2 3 4 5
UPPER GOVERNOR BRACKET....................................................................
LOWER GOVERNOR BRACKET ...................................................................
FLANGED HEX HEAD BOLT, M6 - 1 X 12MM LG..........................................
FLANGED HEX HEAD BOLT, M6 - 1 X 30MM LG..........................................
FLANGED HEX NUT, M6 - 1...........................................................................
GOVERNOR LEVER BUSHING .....................................................................
GOVERNOR ROD ..........................................................................................
GOVERNOR ROD GUARD ............................................................................
FLANGED HEX HEAD BOLT, M6 - 1 X 20MM LG..........................................
FLANGED HEX HEAD BOLT, M8 - 1.25 X 16MM LG.....................................
GOVERNOR CABLE / DIRECTION SELECTOR BRACKET
(FOR VEHICLES MANUFACTURED UNTIL APRIL 19, 2014) .......................
FLANGED HEX HEAD BOLT, M10 - 1.25 X 25MM LG...................................
GOVERNOR WARNING LABEL.....................................................................
NYLON CLAMP, 8" LG (NOT ILLUSTRATED) ...............................................
GOVERNOR CABLE / DIRECTION SELECTOR BRACKET
(FOR VEHICLES MANUFACTURED FROM APRIL 20, 2014).......................
653637 Service Parts Manual
DESCRIPTION
ACCELERATOR
QTY.
1
1
1
1
1
1
1
1
1
1
1
2
1
2
1
Page A-6
