Choke Cable - Textron EZGO TXT Valor Service & Parts Manual

When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
1 607954
2 603580
3 607683
4 608021
5 603585
6 603584
7 603586
8 603587
9 603588
10 603589
11 603590
12 603592
13 603591
14 603583
15 603598
16 603596
17 603597
18 603594
19 603593
20 603595
21 608023
22 603581
23 607684
24 607682
25 607681
26 605868
27 00568G4
28 00545G4
29 72155G01
30 72154G01
1 2 3 4 5
CARBURETOR (INCLUDES ITEMS 2 - 22) .......................................................
CARBURETOR MOUNT GASKET...............................................................
MAIN JET (#104) (FOR ELEVATIONS OF 3000FT - 6000 FT) ....................
PILOT JET (#44)...........................................................................................
PLUG............................................................................................................
STUD BOLT..................................................................................................
NEEDLE VALVE ...........................................................................................
FLOAT ..........................................................................................................
FLOAT PIN ...................................................................................................
FLOAT BOWL GASKET ...............................................................................
FLOAT CHAMBER .......................................................................................
CHAMBER PLUG.........................................................................................
BOWL GASKET............................................................................................
CHOKE BRACKET.......................................................................................
BREATHER TUBE........................................................................................
INTAKE TUBE CLAMP .................................................................................
CLAMP CYLINDER HEAD TUBE.................................................................
INTAKE TUBE ..............................................................................................
CHOKE GASKET .........................................................................................
HEX NUT, M6 - 10 ........................................................................................
THROTTLE ROD ATTACHMENT BUSHING ...............................................
CARBURETOR INSULATOR ......................................................................
MAIN JET (#102) (FOR ELEVATIONS OF 3000 FT - 6000 FT) .........................
LABEL, HIGH ALTITUDE JET, 6000 FT (NOT ILLUSTRATED)..........................
LABEL, HIGH ALTITUDE JET, 3000 FT - 6000 FT (NOT ILLUSTRATED) .........

CHOKE CABLE ..................................................................................................

LOCK WASHER (EXTERNAL TOOTH TYPE), 9/16" .........................................
JAM NUT, 9/16 "- 18 ...........................................................................................
RETAINER ..........................................................................................................
CHOKE ADAPTER..............................................................................................
653637 Service Parts Manual
CARBURETOR AND CHOKE
DESCRIPTION QTY.
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
1
1
1
1
1
1
1
1
1
1
Page F-2
