HOW TO USE THE SERVICE PARTS MANUAL
1. WHEN THE PART NUMBER IS NOT KNOWN
•
Determine the function and application of the part required. Turn to the TABLE OF CONTENTS and select the
most appropriate component description.
•
Turn to the page number indicated and locate the part description in the parts list. Read the full accompanying
description for specific information regarding the part that was not shown in the index.
•
From the parts list, obtain the item number assigned to it and confirm that the part selected is correct by verifying
it with the pictorial representation on the illustrated page.
2. IF YOU KNOW THE PART NUMBER
•
Locate the part number or description in the appropriate column on the parts list page.
NOTE: It is suggested that you confirm that the part selected is correct by verifying it with the pictorial representation on
the illustrated page.
Should an asterisk (*) appear in the part number column on the parts list page, read upwards until a part number is
found. The part number is the lowest assembly sold by Service Parts. The asterisk (*) indicates that the part depicted is
not available for purchase.
NOTE: Descriptions are indented under the assembly that they are used on. That assembly is, in turn listed under the
assembly that it is used on. This process is repeated until the highest final assembly is reached.
To facilitate the maintenance and repair of the vehicle, a Technician's Repair and Service Manual is
available from the Service Parts Department.
Page vi
Title
106
*See Body Section for
decal information
102,104 107
Front of Vehicle
79
103
105
83,88
81,86
101
84,89
100
82,87 99
98
94
96
95
64 74
91
63 70
65
92 69
120
62
71
123
66
67
116
113
73
72
118
121
119
122
111
131
112
115 114
126
127
128 129
Left hand
illustration page
Service Parts Manual
Title
Parts list (continued on
rear of page if required)
