Textron EZGO TXT Valor Service & Parts Manual page 30

BODY
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
28 71578G01
29 00571G2
30 71102G01
31 71514G01
32 14601G17
33
34
35 615239
36 617333
37 15058G6
38
39
40
41
42
43 634161
44 23726G4
45 601476
46 625246
47 625244
48 627564
49 627563
50
51 656538
52 651127G01
53 651127G02
54 656649
55 16816G1
Page C-9
1 2 3 4 5
REAR BUMPER ..............................................................................................
FLAT WASHER, 5/16" .....................................................................................
HEX HEAD BOLT, 1/4" - 20 X 3/4" LG.............................................................
BUMPER PLUG ..............................................................................................
RIVET (ALUMINUM), 3/16" X 9/16".................................................................
ROCKER PANEL WITH SILL PLATE (DRIVER SIDE)....................................
ROCKER PANEL WITH SILL PLATE (PASSENGER SIDE) ...........................
RIVET (ALUMINUM), 3/16" X 15/16"...............................................................
HEXALOBULAR FLANGE BOLT, M6 - 1 X 34.5MM LG .................................
SPACER, 5/16"................................................................................................
LOCK NUT, M6 - 1...........................................................................................
REAR REFLECTOR (RED) (PASSENGER SIDE) (NOT ILLUSTRATED) ......
REAR REFLECTOR (RED) (DRIVER SIDE) (NOT ILLUSTRATED) ..............
REAR REFLECTOR (RED) (PASSENGER SIDE) .........................................
REAR REFLECTOR (RED) (DRIVER SIDE) .................................................
SPLASHGUARD FRONT-KIT (INCLUDES ITEMS 52 - 54) ...........................
SPLASH GUARD (DRIVER SIDE) ...........................................................
SPLASH GUARD (PASSENGER SIDE) ..................................................
SPLASHGUARD HARDWARE KIT (INCLUDES ITEM 55) ......................
RATCHET RIVET, .25" X .680"...............................................................
653637 Service Parts Manual
DESCRIPTION QTY.
1
4
4
4
4
1
1
4
4
4
4
1
1
1
1
1
1
1
1
4
