- Page 1 H330SS LGA Module Hardware User Manual Version: V1.0.0 Date: 2013-05-14...
- Page 2 Copyright ©2013 Fibocom Wireless Inc. All rights reserved. Trademarks Notice The FIBOCOM Logo is registered by Fibocom Wireless Inc. All other product or service names or logos are the property of their respective owners. Copyright ©2013 Fibocom Wireless Inc. All rights reserved.
-
Page 3: Table Of Contents
5.2.3 Power off Signal ................................. 23 5.2.4 Reset Signal ................................. 23 Indicator Signal ..................................24 5.3.1 Pin Description ................................24 5.3.2 Indicator Description ............................... 24 USB Interface ..................................25 5.4.1 USB Interface Description ............................25 H330SS LGA Module Hardware User Manual Page 3 of 38... - Page 4 RF PCB Design ..................................37 7.2.1 Layout Guideline ............................... 37 7.2.2 Impedance ................................... 37 Antenna Design ................................... 37 7.3.1 Main Antenna Design Requirements ........................ 37 7.3.2 Diversity Antenna Design ............................38 H330SS LGA Module Hardware User Manual Page 4 of 38...
-
Page 5: Preface
3GPP TS 22.004 -v6.0.0: General on supplementary services 3GPP TS 23.090 -v6.1.0: Unstructured Supplementary Service Data (USSD); Stage 2 3GPP TS 24.008 v6.19, Mobile radio interface Layer 3 specification; H330SS LGA Module Hardware User Manual Page 5 of 38... -
Page 6: Introduction
2G Talk: 260mA (GSM PCL5) Class 4 (2W)：850/900 MHz, GSM Class 1 (1W)：1800/1900 MHz, GSM Tx Power Class E2 (0.5W)：850/900 MHz, EDGE (Typical Value) Class E2 (0.4W)：1800/1900 MHz, EDGE Class 3 (0.25W)：850/900/1900/2100 MHz, WCDMA H330SS LGA Module Hardware User Manual Page 6 of 38... - Page 7 Gain Control, Echo Suppression, Noise Suppression, Side Tone Character Set IRA, GSM, UCS2, HEX FIBOCOM proprietary AT commands AT Commands GSM 07.05, GSM 07.07 Accessories Firmware Loader Tool over USB/UART, User Manual, Developer Kit H330SS LGA Module Hardware User Manual Page 7 of 38...
-
Page 8: Appearance
2.3 Appearance The following picture shows the H330S Wireless Communication Module. Top view: Figure 2-1 Bottom view: Figure 2-2 H330SS LGA Module Hardware User Manual Page 8 of 38... -
Page 9: Mechanical
3 Mechanical 3.1 Dimensions Figure 3-1 3.2 PCB Layout Design Figure 3-2 H330SS LGA Module Hardware User Manual Page 9 of 38... -
Page 10: Hardware Overview
Ext. Memory 32KHz XO VBACKUP Interface Duplexer CLK in VCTCXO Nand 1Gb + DDR 256Mb MIC +/- EAR +/- Audio Codec AUXI +/- AUXO +/- Output:1.8V Vspeaker Ant_main Ant_div Figure 4-1 H330SS LGA Module Hardware User Manual Page 10 of 38... -
Page 11: Pin Definition
Module main power input, voltage range: 3.3V ~ 4.2V VBAT VBAT Power supply indicator for RF PA VTRX Power supply indicator for RF transceiver 1.8V voltage output inside module VRTC Backup battery power input. H330SS LGA Module Hardware User Manual Page 11 of 38... - Page 12 MIC- Main MIC input signal- AUXI- Auxiliary MIC input signal - AUXI+ Auxiliary MIC input signal + AGND Audio GND Audio codec speaker part power supply, connect to VSPK VBAT H330SS LGA Module Hardware User Manual Page 12 of 38...
- Page 13 UART1 Carrier Detect UART1_CTS UART1 Clear To Send UART1 Request To Send UART1_RTS UART1_TXD UART1 Transmitted Data UART1_RXD UART1 Received Data UART2 UART2_TXD UART2 Transmitted Data UART2_RXD UART2 Received Data H330SS LGA Module Hardware User Manual Page 13 of 38...
- Page 14 HSIC USB pulse signal ( not supported) Antenna ANT_MAIN Main antenna interface, 50 ohm Impedance ANT_DIV Diversity antenna interface, 50 ohm Impedance Others CLKOUT0 Digital audio clock output Sleep Mode Indicator Status Indicator Not Connect H330SS LGA Module Hardware User Manual Page 14 of 38...
- Page 15 H330SS LGA Module Hardware User Manual Page 15 of 38...
- Page 16 H330SS LGA Module Hardware User Manual Page 16 of 38...
-
Page 17: Hardware Interface
Condition Typical Value Unit I off RTC mode I idle Idle mode WCDMA Low power I sleep mode GSM voice - 1 TX slot GSM850 PCL GSM-RMS 1 Rx slot H330SS LGA Module Hardware User Manual Page 17 of 38... - Page 18 EGSM900 PCL DCS1800 PCL PCS1900 PCL GSM850 PCL GPRS Class 33 - 4 TX slot EGSM900 PCL GPRS-RMS 1 Rx slot DCS1800 PCL H330SS LGA Module Hardware User Manual Page 18 of 38...
- Page 19 EGPRS Class 33 - 4 TX slot EGPRS-RMS 1 Rx slot DCS1800 PCL PCS1900 PCL 1655 GSM850 PCL 1715 Peak current GSM-MAX During TX slot EGSM900 PCL 1050 DCS1800 PCL H330SS LGA Module Hardware User Manual Page 19 of 38...
- Page 20 1100 PCS1900 PCL 24dBm 0dBm Band5 (850) -24dBm -50dBm 24dBm 0dBm Band2 (1900) -24dBm -50dBm WCDMA WCDMA-RMS 24dBm 0dBm Band1 (2100) -24dBm -50dBm 24dBm 0dBm Band8 (900) -24dBm -50dBm H330SS LGA Module Hardware User Manual Page 20 of 38...
-
Page 21: Vio
R8 is the current-limiting resistance in order to ensure VRTC working normally. When it is working fine, R8 ≥1kohm VRTC Current consumption < 2uA; C9 value can affect RTC hold time H330SS LGA Module Hardware User Manual Page 21 of 38... -
Page 22: On/Off And Reset
The following table shows the burst timing: Parameter Condition Minimum Value Typical Value Maximum Value Unit Pulse Width 3000 Timing control: VBAT POWER_ON 300mS VDD_1V8 Figure 5-2 Reference design: Figure 5-3 H330SS LGA Module Hardware User Manual Page 22 of 38... -
Page 23: Power Off Signal
If the module is connected to PC, you can see PC Virtual port restarts. Note: Reset signal is sensitive, when PCB layout, please keep it away from radio frequency interference, add debouncing capacitor near the module end is recommended. H330SS LGA Module Hardware User Manual Page 23 of 38... -
Page 24: Indicator Signal
Status Mode idle(unregistered 600ms high level, 600ms low level idle(registered) 75ms high level, 3S low level Call low level Data communicating 75ms high level, 75ms low level Sleep high level H330SS LGA Module Hardware User Manual Page 24 of 38... -
Page 25: Usb Interface
USB_ID — USB ID signal VUSB USB power input USB_TEST — USB TEST signal H330S wireless communication module supports USB 2.0. Install the corresponding USB driver before use on PC. H330SS LGA Module Hardware User Manual Page 25 of 38... -
Page 26: Usb Interface Application
The layout design of this circuit on the AP board should comply with the USB 2.0 high speed protocol, with differential lining and impedance control to 90 ohm. H330SS LGA Module Hardware User Manual Page 26 of 38... -
Page 27: Uart Interface
UART1 Clear to send UART1_RTS UART1 Request to send UART1_TXD UART1 Transmitted Data UART1_RXD UART1 Received Data UART2 Pin# Pin Name Description UART2_RXD UART2 Transmitted Data UART2_TXD UART2 Received Data H330SS LGA Module Hardware User Manual Page 27 of 38... -
Page 28: Uart Design
When UART1 communicating with PC, first shift from 1.8V to 3.3V, and then uses SP3238 to shift. When UART2 communicating with PC, first shift from 1.8V to 3.3V, and then uses SPIEX3232EEA to shift level. Notice the signal direction when shift level. H330SS LGA Module Hardware User Manual Page 28 of 38... -
Page 29: Ring Indicator
USIM_CLK USIM clock signal USIM_IO USIM data signal USIM ground USIM insert detect signal USIM_CD High level indicates SIM card is not inserted Low level indicates SIM card is inserted H330SS LGA Module Hardware User Manual Page 29 of 38... -
Page 30: Usim Design
The SIM card signals should be protected from ESD using very low capacitance protective elements (like Zener diode). The recommended part no of ESD is AVR-M1005C080MTAAB (TDK). ESD component should layout with SIM hold closely. H330SS LGA Module Hardware User Manual Page 30 of 38... -
Page 31: Usim Hot Plug
Audio channel1 MIC signal input- AUXI- Audio channel2 MIC signal input - AUXI+ Audio channel2 MIC signal input + AGND Audio GND VSPK Audio codec speaker part power supply, connect to VBAT H330SS LGA Module Hardware User Manual Page 31 of 38... -
Page 32: Audio Description
The VSPK can be straight connected to VBAT. Audio channel 2: AUXI input characteristic: Parameter Test conditions Minimum Value Typical Value Maximum Value Unit Bias voltage No load Programmable， Gain steps gain:2dB Load resistance Kohm H330SS LGA Module Hardware User Manual Page 32 of 38... -
Page 33: Digital Audio
H330S Signal Direction Audio CODEC I2S Port I2S2_CLK0 I2S_CLK I2S2_WA0 I2S_LRCK I2S2_RX I2S_SDIN I2S2_TX I2S_SDOUT CLKOUT0 I2S_MCLK 5.8.2 I2C H330S Signal Direction Audio CODEC I2C Port I2C_SDA I2C_SDA I2C_SCL I2C_SCL H330SS LGA Module Hardware User Manual Page 33 of 38... -
Page 34: Others
It supports many audio sample rates (48 KHz, 44.1 KHz, 32 KHz, 24 KHz, 22.5 KHz, 16 KHz, 12 KHz, 11.025 KHz and 8 KHz). 5.9 Others The module does not support interface like GPIO、MIPI、MMC、DAC yet. H330SS LGA Module Hardware User Manual Page 34 of 38... -
Page 35: Electrical And Environmental Features
Minimum Value Maximum Value Unit VBAT Digital Signal 6.2 Environmental Features This table shows the environmental features of H330S. Parameter Minimum Value Maximum Value Unit Operational Temperature °C Storage Temperature °C H330SS LGA Module Hardware User Manual Page 35 of 38... -
Page 36: Rf Interface
Operating Band UMTS 2100 (Band I IMT) 2110–2170 MHz UMTS 1900 (Band II PCS) 1930–1990 MHz UMTS 850 (Band V CLR) 869–894 MHz UMTS 900 (Band VIII GSM) 925–960 MHz H330SS LGA Module Hardware User Manual Page 36 of 38... -
Page 37: Rf Pcb Design
The polarization of an antenna is the orientation of the electric field vector that rotates with time in the direction of maximum radiation. Linear polarization is recommended: it would be better if the polarization direction of diversity antenna is different from main antenna. H330SS LGA Module Hardware User Manual Page 37 of 38... -
Page 38: Diversity Antenna Design
The design methods of diversity antenna and main antenna are the same, its efficiency indicators allows to reduce 3dB. The isolation between main antenna and diversity antenna should be higher than 12dB. H330SS LGA Module Hardware User Manual Page 38 of 38... - Page 39 RF Modules Click to view products by manufacturer: Fibocom Other Similar products are found below : HMC-C009 HMC-C011 nRF24L01P-MODULE-PCB HMC-C021 HMC-C024 XB9XT-DPRS-721 XBP9B-DMUTB022 nRF24L01P- MODULE-SMA CMD-KEY2-418-CRE XM-C92-2P-UA XB9XT-DPUS-721 V640-A90 HMC-C583 MAAM-008818-TR3000 MTSMC- H5-U SIMSA868-PRO SIMSA915C-PRO SIMSA868C-PRO SIMSA433C-PRO SIMSA915-PRO XBP9B-DMUT-042 HMC-C582 HMC-...
