- Page 1 L830-EB-11 Hardware User Manual Version: V1.0.2 Update date: 2017.09.21 Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EBHardware User Manual Page 1 of 39...
- Page 2 Applicability Table Product model Description L830-EB-11 Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 2 of 39...
- Page 3 1. Update timing of power on/off and reset V1.0.1 2017-09-21 2. Modify the RF Band 3. Modify the packing description Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 3 of 39...
-
Page 4: Table Of Contents
3.5.1 USIM Pins............................22 3.5.2 USIM Interface Circuit........................23 3.5.2.1 N.C. SIM Card Slot............................23 3.5.2.2 N.O. SIM Card Slot............................23 3.5.3 USIM Hot-Plugging..........................24 Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 4 of 39... - Page 5 5.4 M.2 Connector............................. 37 5.5 Storage................................37 5.5.1 Storage Life............................37 5.6 Packing................................. 37 5.6.1 Tray Package............................38 5.6.2 Tray size............................39 Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 5 of 39...
-
Page 6: Preface
Related Documents RF Antenna Application Design Specification L8-Family System Driver Integration and Application Guidance L8-Family AT Commands Manual Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 6 of 39... - Page 7 EU Regulator Conformance Hereby, We, Fibocom Wireless Inc. declares that the radio equipment type L830-EB-11 is in compliance with the Directive 2014/53/EU. In all cases assessment of the final product must be mass against the Essential requirements of the Directive 2014/53/EU Article 3.1(a) and (b), safety and EMC respectively, as well as any relevant Article 3.2 requirements.
- Page 8 Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 9 Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This device is intended only for OEM integrators under the following conditions: External antenna is used with the module during the testing process, the maximum antenna gain for External antenna is used with the module during the testing process, the maximum antenna gain frequency<1G is 3dBi, for frequency>1G is 5 dBi and the antenna separation distance is 20cm.
-
Page 10: Overview
Weight: About 5.8 g Interface WWAN Main Antenna x 1 Antenna Connector WWAN Diversity Antenna x 1 USIM 3V/1.8V Function Interface Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 7 of 39... -
Page 11: Application Framework
3GPP specifications. 2.3 Application Framework The peripheral applications for L830 module are shown in Figure 2-1: Figure2-1 Application Framework Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 8 of 39... -
Page 12: Hardware Framework
Figure 2-2 Hardware Framework 3 Application Interface M.2 Interface The L830 module uses standard M.2 Key-B interface, with a total of 75 pins. Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 9 of 39... -
Page 13: Pin Map
3.1.1 Pin Map Figure 3-1 Pin Map Note: Pin “Notch” represents the gap of the gold fingers. Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 10 of 39... -
Page 14: Pin Definition
Not connected, L830 M.2 module is 21 CONFIG_0 configured as the WWAN-SSIC 0 interface type. 22 I2S_RX I2S serial data input CMOS 1.8V Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 11 of 39... - Page 15 43 NC 44 GNSS_IRQ Reserved CMOS 1.8V 45 GND Power Supply 46 SYSCLK 26MHz clock output 1.8V 47 NC Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 12 of 39...
- Page 16 External reset input signal, internal 67 RESET# CMOS 1.8V 100KΩ pull-up. 68 NC 69 CONFIG_1 Connected to internal GND, L830 Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 13 of 39...
-
Page 17: Power Supply
Pin Name Pin Description Minimum Typical Maximum Value Value Value 2,4,70,72,74 +3.3V Power supply input 3.135 UIM_PWR USIM power supply 1.8V/3V Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 14 of 39... -
Page 18: Power Supply
1A, so the power source should be not lower than 3.135V, or the module may shut down or reboot. The power supply limits are shown in Figure 3-3: Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual... -
Page 19: Logic Level
In the condition of 3.3V power supply, the L830 power consumption as shown in the following table: Average Parameter Mode Condition Current(mA) Power off Power supply, module power off 0.29 DRX=6 WCDMA DRX=8 Sleep DRX=9 Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 16 of 39... -
Page 20: Control Signal
The FULL_CARD_POWER_OFF# pin needs an external 3.3V or 1.8V pull up for booting up. The VDD(3.3V/1.8V) should be provided from the external circuit. Two methods for module starting up: Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual... -
Page 21: Start-Up Timing Sequence
After about 10s time, the module completes the initialization process. The start-up timing is shown in Figure 3-6: Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 18 of 39... -
Page 22: Module Shutdown
PMU will be powered off. The software control timing is shown in Figure 3-7: Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 19 of 39... -
Page 23: Module Reset
Figure 3-8: Figure 3-8 Recommended Design for Reset Circuit The reset control timing is shown in Figure 3-9: Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 20 of 39... -
Page 24: Usb Interface
0.3---3V, USB2.0 USB_D- USB Data Minus 0.3---3V, USB2.0 3.4.2 USB Interface Application The reference circuit is shown in Figure 3-10: Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 21 of 39... -
Page 25: Usim Interface
UIM_PWR USIM power supply 1.8V/3V UIM_RESET USIM reset 1.8V/3V UIM_CLK USIM clock 1.8V/3V UIM_DATA USIM data, internal 4.7K pull-up 1.8V/3V Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 22 of 39... -
Page 26: Usim Interface Circuit
3.5.2.2 N.O. SIM Card Slot The reference circuit design for N.O. (Normally Open) SIM card slot is shown in Figure 3-12: Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 23 of 39... -
Page 27: Usim Hot-Plugging
The SIM card hot-plugging detect function is disabled. AT+MSMPD=0 Disable The module reads the SIM card when starting up, and the SIM_DETECT status will not be detected. Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 24 of 39... -
Page 28: Usim Design
Reset Value Pin Description Type System status LED, drain LED1# CMOS 3.3V output. WOWWAN# CMOS 1.8V Module wakes up Host (AP). Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 25 of 39... -
Page 29: Led#1 Signal
Ringing /SMS or data requests Pull low 1s then pull high (pulse signal). Idle/Sleep High level The WOWWAN# timing is shown in Figure 3-14: Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 26 of 39... -
Page 30: Interrupt Control
High/Floating WWAN function is enabled, the module exits the Flight mode. WWAN function is disabled, the module enters Flight mode. Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 27 of 39... -
Page 31: Body Sar
The L830 module supports I2S digital audio interface and it supports the ordinary I2S mode and PCM mode. The signal level of the I2S interface is 1.8V. Please refer to “FIBOCOM Digital Voice” description for detailed application design. The definition of I2S signals is as follows:... -
Page 32: Pcm Mode
The L830 module supports one I2C interface, which is configured as I2C master by default. The I2C master is used for driving external I2C slave devices, such as the Audio Codec. Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual... -
Page 33: Clock Interface
Module Type and Main Port (pin21) (pin69) (pin75) (pin1) Host Interface Configuration WWAN-SSIC Please refer to “PCI_Express_M.2_Specification_Rev1.1” for more details. Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 30 of 39... -
Page 34: Other Interfaces
4.1.2 RF Connector Characteristic Rated Condition Environment Condition Frequency Range DC to 6GHz Temperature Range Characteristic Impedance 50Ω –40°C to +85°C Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 31 of 39... -
Page 35: Rf Connector Dimension
Figure 4-2 RF connector dimensions Figure 4-3 0.81mm coaxial antenna dimensions Figure 4-4 Schematic diagram of 0.81mm coaxial antenna connected to the RF connector Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 32 of 39... -
Page 36: Operating Band
The receiver sensitivity for each band of the L830 module as shown in the following table: Rx Sensitivity(dBm) Mode Band 3GPP Requirement Note Typical WCDMA Band I -106.7 -110 BER<0.1% Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 33 of 39... -
Page 37: Gnss
LTE Band 8(900): 80 MHz LTE band 20(800): 71 MHz LTE band 28(850): 100 MHz LTE band 32(700): 11 MHz Impedance 50 Ohm Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 34 of 39... -
Page 38: Structure Specification
The product appearance for L830 module is shown in Figure 5-1: Figure 5-1 Module Appearance Dimension of Structure The structural dimension of the L830 module is shown in Figure 5-2: Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 35 of 39... -
Page 39: Interface Model
M.2 interface definition, L830 module adopts Type 3042-S3-B interface (30x42mm, the component maximum height on t top layer is 1.5mm, PCB thickness is 0.8mm, and KEY ID is B). Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual... -
Page 40: Connector
Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 37 of 39... -
Page 41: Tray Package
The L830 module uses tray package, 20 pcs are packed in each tray, with 5 trays in each box and 6 boxes in each case. Tray packaging process is shown in Figure 5-4: Figure 5-4 Tray Packaging Process Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 38 of 39... -
Page 42: Tray Size
6.0±0.3 0.5±0.1 43±0.3 33.0±0.3 ITEM 294.0±0.3 159.0±0.3 20.0±0.5 9.0±0.5 24.5±0.5 187.5±0.2 ITEM 105.0±0.2 9.0±0.2 Figure 5-5 Tray Size (Unit: mm) Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. L830-EB-11 Hardware User Manual Page 39 of 39...
