OPERATOR'S MANUAL
MODEL #200987
4500W WIRELESS REMOTE
START INVERTER GENERATOR
REGISTER YOUR PRODUCT ONLINE
at championpowerequipment.com
or visit championpowerequipment.com
SAVE THESE INSTRUCTIONS. This manual contains important safety precautions which should be read and understood before operating the product. Failure to do
so could result in serious injury. This manual should remain with the product.
Specifications, descriptions and illustrations in this manual are as accurate as known at the time of publication, but are subject to change without notice.
This product meets the requirements of the PGMA (Portable Generator Manufacturers' Association) standard ANSI/PGMA G300-2015 (Safety and Performance of
Portable Generators).
REV 20201019
Champion Power Equipment, Inc., Santa Fe Springs, CA USA

Advertisement

Table of Contents
loading

Related Manuals for Champion Global Power Equipment 200987

Summary of Contents for Champion Global Power Equipment 200987

  • Page 1 OPERATOR'S MANUAL MODEL #200987 4500W WIRELESS REMOTE START INVERTER GENERATOR REGISTER YOUR PRODUCT ONLINE at championpowerequipment.com or visit championpowerequipment.com SAVE THESE INSTRUCTIONS. This manual contains important safety precautions which should be read and understood before operating the product. Failure to do so could result in serious injury.
  • Page 2 CARBON MONOXIDE SAFETY: THE BIG PICTURE As the only safe way to use a portable generator, taking your generator outside is absolutely mandatory to keep your family safe from carbon monoxide. But there’s even more you can do. By educating yourself about all carbon monoxide risks, you’ll be better prepared to protect your family from this colorless, oderless threat.

  • Page 3: Table Of Contents

    TAbLE Of CONTENTS 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR TAbLE Of CONTENTS Maintenance ..........Cleaning the Generator .......... Introduction ...........

  • Page 4: Introduction

    INTRODUCTION 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR INTRODUCTION SAfETY DEfINITIONS Congratulations on your purchase of a Champion Power Equipment The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols, and their explanations, (CPE) product.

  • Page 5: Important Safety Instructions

    IMPORTANT SAfETY INSTRUCTIONS 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR IMPORTANT SAfETY INSTRUCTIONS DANGER  Operate equipment with guards in place. WARNING  Rotating parts can entangle hands, feet, hair, clothing and/or Cancer and Reproductive Harm – www.P65Warnings.ca.gov accessories. Traumatic amputation or severe laceration can result.
  • Page 6 IMPORTANT SAfETY INSTRUCTIONS 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR WARNING CAUTION   Spark from removed spark plug wire can result in fire or Improper treatment or use of the generator can damage it, electrical shock. shorten its life or void the warranty.

  • Page 7: Fuel Safety

    IMPORTANT SAfETY INSTRUCTIONS 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR fuel Safety When transporting or servicing the generator: Always check that the fuel valve is in the OFF position and the DANGER  gasoline tank is empty. For LPG compatible models, check that the LPG cylinder is GASOLINE AND GASOLINE VAPORS ARE HIGHLY disconnected and stored securely away from the generator.

  • Page 8: Lithium-Ion Battery Safety

    IMPORTANT SAfETY INSTRUCTIONS 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR Lithium-ion battery Safety When storing the generator/battery: – Always check that the battery connectors between the inverter Electrolyte inside the battery is harmful to skin and eyes. If the and the battery are unplugged and placed away from the battery leaks and electrolyte gets in your eyes, do not rub them.

  • Page 9: Safety And Dataplate Labels

    IMPORTANT SAfETY INSTRUCTIONS 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR Safety and Dataplate Labels These labels warn you of potential hazards that can cause serious injury. Read them carefully. If a label comes off or becomes hard to read, contact Technical Support Team for possible replacement.

  • Page 10: Safety Symbols

    IMPORTANT SAfETY INSTRUCTIONS 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR Safety Symbols Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to more safely operate the product.
  • Page 11 IMPORTANT SAfETY INSTRUCTIONS 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR SYMBOL MEANING This product uses lithium-ion (Li-ion) batteries. Local, state, or federal laws may prohibit disposal of batteries in ordinary trash. Consult your local waste authority for information regarding available recycling and/or disposal options.

  • Page 12: Operation Symbols

    IMPORTANT SAfETY INSTRUCTIONS 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR Operation Symbols Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to more safely operate the product.

  • Page 13: Quick Start Label Symbols

    IMPORTANT SAfETY INSTRUCTIONS 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR Quick Start Label Symbols Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to more safely operate the product.

  • Page 14: Controls And Features

    CONTROLS AND fEATURES 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR CONTROLS AND fEATURES Read this operator’s manual before operating your generator. Familiarize yourself with the location and function of the controls and features. Save this manual for future reference.

  • Page 15: Control Panel

    CONTROLS AND fEATURES 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR Control Panel 1. Intelligauge with Power Meter – See Intelligauge with RECEPTACLES Power Meter section. (2×) 120V AC, 20A (NEMA 5-20R) 2. Ignition Switch – Used to START the generator.

  • Page 16: Intelligauge With Power Meter

    CONTROLS AND fEATURES 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR Intelligauge with Power Meter The meter is divided into two seperate displays. The LCD displays each mode for several seconds and then automatically cycles through. The Power Meter LED displays output in percent (%) with 100% at the top.

  • Page 17: Wireless Remote Control

    CONTROLS AND fEATURES 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR Wireless Remote Control fCC Statement for Remote Control Device This generator is equipped with a wireless remote control system 1. This device complies with Part 15 of the FCC Rules. Operation for starting and stopping.

  • Page 18: Parts Included

    CONTROLS AND fEATURES 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR Parts Included Accessories Engine Oil ........16.9 fl. oz. (500 ml) Oil Funnel ..

  • Page 19: Assembly

    ASSEMbLY 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR ASSEMbLY Connect the battery 1. Remove the non recoil side maintenance cover by removing Your generator requires some assembly. It must be properly the two screws with a phillips head screw driver serviced with fuel and oil before operation.

  • Page 20: Add Fuel

    ASSEMbLY 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR 1. Place the generator on a flat, level surface. NOTICE  2. Turn the oil access cover fastener to the unlocked position Once oil has been added, a visual check should show oil about and remove the cover.
  • Page 21 ASSEMbLY 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR Use clean, fresh, regular unleaded gasoline with a minimum CAUTION  octane rating of 87 and an ethanol content of 10% or less by volume. y b c Use unleaded gasoline with a minimum octane rating of 87 and an ethanol content of 10% or less by volume.

  • Page 22: Grounding

    OPERATION 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR OPERATION Grounding Your generator must be properly connected to an appropriate Generator Location ground to help prevent electric shock. WARNING  WARNING  Failure to properly ground the generator can result in electric NEVER operate the generator inside any building, garage, shock.

  • Page 23: Surge Protection

    OPERATION 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR Wet Conditions Alert: Do not expose to rain or use in damp 3. Push and hold the wireless set button found on the locations except as follows: Intelligauge for approximately three seconds until the button LED illuminates blue.

  • Page 24: Starting The Engine

    OPERATION 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR 6. Push and hold the wireless set button approximately three 2. Turn the EZ Start Dial to the “ON” position. seconds until the blue LED on wireless set button turns off.
  • Page 25 OPERATION 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR 3. Turn the EZ Start Dial to the “ON” position. 6. Do not over-choke. As soon as engine starts, push the choke button one time to set the choke to the “RUN” position. Choke button will no longer be illuminated when in “RUN”...

  • Page 26: Manual Choke Start

    OPERATION 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR Manual Choke Start 4. Push the choke button one time to set the choke to the “CHOKE” position. Choke button will illuminate when in If the battery is dead or not able to produce enough current to “CHOKE”...

  • Page 27: Connecting Electrical Loads

    OPERATION 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR 5. Pull the recoil cord until resistance is felt, then pull rapidly. WARNING  Always remember to plug your appliances directly into the generator and do not plug the generator power cord into any electrical outlet or connect to the circuit breaker panel in your home.

  • Page 28: Eco (Economy) Mode

    OPERATION 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR Eco (Economy) Mode 4. If the generator power output is cut off due to an overload condition indicated by the AC overload blinking light, lower The Eco Mode button can be activated to turn on economy control...

  • Page 29: Parallel Operation

    Parallel Operation the wireless remote and electric start feature will no longer The Champion model 200987 is parallel ready and can be function. operated in parallel with another Champion unit to increase the total available electrical power.

  • Page 30: Moving The Generator

    OPERATION 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR 3. Turn the EZ Start Dial to the “OFF” position. 3. While maintaining balance, roll the generator to the desired location. 4. If battery switch is in the “ON” position, press the battery switch to the “OFF”...

  • Page 31: Maintenance

    MAINTENANCE 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR 1. Use a damp cloth to clean exterior surfaces of the generator. WARNING  2. Use a soft bristle brush to remove dirt and oil. Operation using the alternative main jet at elevations lower 3.

  • Page 32: Cleaning And Adjusting The Spark Plug

    MAINTENANCE 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR 2. Locate the air filter plastic cover and remove by pinching the NOTICE  clips together and pulling the cover off. Once oil has been added, a visual check should show oil about 1-2 threads from running out of the fill hole.

  • Page 33: Generator Battery

    MAINTENANCE 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR Charge the Battery 6. Position the spark arrestor and spark arrestor screen on the muffler and cover plate and screws removed in step 2. For a generator equipped with batteries for electric starting, proper battery maintenance and storage should be followed.

  • Page 34: Adjusting The Governor

    STORAGE 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR STORAGE Adjusting the Governor WARNING  WARNING  Tampering with the factory set governor will void your To avoid accidental or unintended ignition of your generator warranty. during periods of storage, the following precautions should be followed: The air-fuel mixture is not adjustable.

  • Page 35: Long Term Storage (More Than 1 Year)

    STORAGE 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR Removing from Storage 10. SLOWLY pull the recoil to rotate the engine to distribute and lubricate the cylinder. NOTICE  11. Re-install the spark plug and spark plug wire. 12. Re-install the maintenance cover.

  • Page 36: Specifications

    SPECIfICATIONS 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR SPECIfICATIONS Oil Specifications DO NOT OVERFILL. Generator Specifications Type ..........*See following chart Generator Model .......... .

  • Page 37: Troubleshooting

    TROUbLESHOOTING 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR TROUbLESHOOTING Problem Cause Solution No fuel. Add fuel. Faulty spark plug. Clean and adjust spark plug or replace. Fill crankcase to the proper level. Low oil level. Place generator on a flat, level surface.
  • Page 38 TROUbLESHOOTING 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR Problem Cause Solution Engine governor defective. Contact the help line. Dirty fuel valve. Clean the fuel valve. Carburetor is dirty and running lean. Contact the help line. Engine hunts or falters.

  • Page 39: Warranty

    WARRANTY 200987 - 4500W WIRELESS REMOTE START INVERTER GENERATOR WARRANTY* Other Exclusions This warranty excludes: CHAMPION POWER EQUIPMENT – Cosmetic defects such as paint, decals, etc. 3 YEAR LIMITED WARRANTY – Wear items such as filter elements, o-rings, etc. Warranty Qualifications –...
  • Page 40 CHAMPION POWER EQUIPMENT, INC. (CPE), THE UNITED STATES ENVIRONMENTAL PROTECTION AGENCY (U.S. EPA) AND THE CALIFORNIA AIR RESOURCES BOARD (CARB) EMISSION CONTROL SYSTEM WARRANTY Your Champion Power Equipment (CPE) engine complies with both the U.S. EPA and state of California Air Resources Board (CARB) emissions regulations.
  • Page 41 EMISSION CONTROL SYSTEM WARRANTY The following are specific provisions relative to your Emission Control System (ECS) Warranty Coverage. 1. APPLICABILITY: This warranty shall apply to 1995 and later model year California small off-road engines (SORE) (for other states, 1997 and later model year engines). The ECS Warranty Period shall begin on the date the new engine or equipment is delivered to its original, end-use purchaser, and shall continue for 24 consecutive months thereafter.
  • Page 42 EMISSION-RELATED PARTS INCLUDE THE FOLLOWING: (using those portions of the list applicable to the engine) Systems covered by this Parts Description warranty Fuel Metering System Fuel regulator, Carburetor and internal parts Air Induction System Air cleaner, Intake manifold Ignition System Spark plug and parts, Magneto ignition system Exhaust System Exhaust manifold, catalytic converter...
