5.7.

5.7. Connector for temperature sensors

Connector for temperature sensors
5.7. 5.7. Connector for temperature sensors Connector for temperature sensors
Connector for up to four temperature sensors.
Compatible sensors:
Temperature sensor inline G1/4 (53066)
●
Temperature sensor inner/outer thread G1/4 (53067)
●
Temperature sensor G1/4 (53147)
●
Temperature sensor plug&cool (53025)
●
Temperature sensor 70 cm (53026)
●
5.8. 5.8. 5.8.

5.8. Connector "RGBpx"

Connector "RGBpx" Connector "RGBpx" Connector "RGBpx"
Connector for up to 90 addressable LEDs. Compatible LED products and special
interconnecting cables are optional accessories and not included in delivery.
If the RGBpx product to be connected has more than one RGBpx connector, the
connector marked with the word "IN" must be used! Additional RGBpx products
may be connected to the "OUT" connector.
Compatible RGBpx products:
RGBpx LED-Strip (53268, 53269, 53270)
●
RGBpx lighting set (53271, 53272)
●
RGBpx Splitty4 (53267)
●
RGBpx LED ring for ULTITUBE (34115)
●
RGBpx LED ring for aqualis (53274, 53276)
●
RGBpx LED ring for 60 mm reservoir (53277)
●
RGBpx cable (53259, 53260, 53261, 53266)
●
5.9.

5.9. Status LED

5.9. 5.9. Status LED Status LED Status LED
The red status LED is continuously on for approximately ten seconds during startup
and then turned off during normal operation. The status LED is blinking during er-
ror conditions, for example after fan output deactivation due to overload or faulty
supply voltage. In case of errors, RGBpx LEDs connected to the device will be
blinking in red, disregarding the current LED controller setup.

6. 6. 6. 6. aquasuite software

aquasuite software
aquasuite software aquasuite software
The Windows software aquasuite is an extensive software suite and can be used
for configuration and monitoring. The software is not required for operation
though. All configuration parameters can be saved into the device's memory.
Please note: Depending on the type of product you are using, some features may
not be available for your device.

6.1. Installation of the aquasuite software

6.1. 6.1. 6.1. Installation of the aquasuite software Installation of the aquasuite software Installation of the aquasuite software
For configuration and monitoring of our products with USB interface, the aqua-
suite software is available for download from our website www.aqua-computer.de.
