Communication Ports
4.4 BNC Ports
Serial RJ45 Port with IRIG-B Support
8
Figure 4.11
a
In RS232 mode, the RJ45 ports conform to EIA-561 DTE, which transmit on TXD and receive on RXD.
Note
Pins 7 and 8 are connected internally. In RS232 mode, these pins enter a high
impedance state. A DTE that asserts RTS will see CTS asserted. However, the device
will not perform hardware flow control.
4.4

BNC Ports

The following BNC ports are available on the PTP module:
1
2
3
Figure 4.12
Inputs are controlled by RUGGEDCOM RS416 and only one can be active at any time.
For information about activating an input, refer to the RUGGEDCOM RUGGEDCOM
RS416 User Guide for the RUGGEDCOM RS416.
The color of the Sync LED on the front panel of the PTP module indicates the status
of the incoming timing signal:
•
•
28
Serial RJ45 Port Pin
Configuration
1 2 3
TTL OUT Port
Sync LED
TTL IN Port
PTP Module
Green – Signal locked
Amber/Yellow – Holdover (GPS lock has been achieved, but the receiver no
longer sees the minimum number of required satellites)
1
Pin RS232 RS485
Mode Mode
1
2 +IRIG-B
3 Common (Isolated) Ground
4 Common (Isolated) Ground
a
5 RXD
a
6 TXD TX/RX+
7 CTS
8 RTS TX/RX-
Shield Chassis Ground
Port
TTL OUT
PPS signal output,
software selectable
TTL IN
Installation Manual, 04/2021, C79000-G8976-1018-10
RS422
Mode
RX-
RX+
TX+
TX-
Function
IRIG-B PWM or 1
TTL-level IRIG-B
PWM signal input
RUGGEDCOM RS416
