Operating Instructions
Capacitive high temperature probe for
level detection
VEGACAP 67
Two-wire
Document ID: 31317

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VEGACAP 67 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vega VEGACAP 67

Summary of Contents for Vega VEGACAP 67

  • Page 1 Operating Instructions Capacitive high temperature probe for level detection VEGACAP 67 Two-wire Document ID: 31317...

  • Page 2: Table Of Contents

    How to proceed if a repair is necessary ................27 Dismount..........................28 Dismounting steps......................28 Disposal ......................... 28 Supplement ..........................29 Technical data ........................ 29 Dimensions ........................32 Industrial property rights ....................35 Trademark ........................35 VEGACAP 67 • Two-wire...
  • Page 3 Contents Editing status: 2020-09-24 VEGACAP 67 • Two-wire...

  • Page 4: About This Document

    Symbols used Document ID This symbol on the front page of this instruction refers to the Docu- ment ID. By entering the Document ID on www.vega.com you will reach the document download. Information, tip, note This symbol indicates helpful additional information.

  • Page 5: For Your Safety

    During work on and with the device, the required personal protective equipment must always be worn. Appropriate use The VEGACAP 67 is a sensor for point level detection. You can find detailed information about the area of application in chapter " Product description". Operational reliability is ensured only if the instrument is properly used according to the specifications in the operating instructions manual as well as possible supplementary instructions.

  • Page 6: Eu Conformity

    That is why we have introduced an environment management system with the goal of continuously improving company environmental pro- tection. The environment management system is certified according to DIN EN ISO 14001. Please help us fulfil this obligation by observing the environmental instructions in this manual: • Chapter " Packaging, transport and storage" • Chapter " Disposal" VEGACAP 67 • Two-wire...

  • Page 7: Product Description

    • Hardware from 1.0.0 • Software from 1.3.0 • Only for instrument versions without SIL qualification Constituent parts The VEGACAP 67 consists of the components: • Process fitting with probe • Housing with electronics • Housing cover, optionally available with display and adjustment module VEGACAP 67 • Two-wire...
  • Page 8 3 Product description Fig. 1: VEGACAP 67 with plastic housing Housing lid Housing with electronics 3 Process fitting Supporting tube Ceramic insulator Type label The type label contains the most important data for identification and use of the instrument: VEGACAP 67 • Two-wire...
  • Page 9 Alternatively, you can access the data via your smartphone: • Download the VEGA Tools app from the " Apple App Store" or the " Google Play Store" • Scan the DataMatrix code on the type label of the instrument or •...

  • Page 10: Principle Of Operation

    3 Product description Principle of operation Application area The VEGACAP 67 is a point level sensor for bulk solids. The probe is designed for high temperature applications. Functional principle Probe, measured product and vessel wall form an electrical capacitor. The capacitance is influenced by three main factors.

  • Page 11: Accessories

    Protective cover The protective cover protects the sensor housing against soiling and intense heat from solar radiation. Flanges Screwed flanges are available in different versions according to the following standards: DIN 2501, EN 1092-1, BS 10, ASME B 16.5, JIS B 2210-1984, GOST 12821-80. VEGACAP 67 • Two-wire...

  • Page 12: Mounting

    Chemical properties of the medium • Abrasion and mechanical influences Switching point In general, VEGACAP 67 must be mounted vertically. The instrument must be mounted in such a way that the probe is at the height of the requested switching point. Welding work Before beginning the welding work, remove the electronics module from the sensor.
  • Page 13 Prior to setup you have to replace these protective caps with ap- proved cable glands or close the openings with suitable blind plugs. VEGACAP 67 • Two-wire...

  • Page 14: Mounting Instructions

    4 Mounting Mounting instructions Agitators and fluidization Due to the effects of agitators, equipment vibration or similar, the level switch can be subjected to strong lateral forces. For this reason, do not use an overly long electrode for VEGACAP 67, but check if you can mount a short level switch on the side of the vessel in horizontal position. Inflowing medium If the instrument is mounted in the filling stream, unwanted false measurement signals can be generated. For this reason, mount the instrument at a position in the vessel where no disturbances, e.g.
  • Page 15 4 Mounting To compensate measurement errors caused by the material cone in cylindrical vessels, the sensor must be mounted at a distance of d/6 from the vessel wall. Fig. 6: Filling and emptying centred VEGACAP 67 • Two-wire...
  • Page 16 Make sure that the max. permissible tensile load of the suspension cable is not exceeded. The danger of this happening exists particu- larly with very heavy solids and large meas. lengths. The max. permis- sible load is stated in chapter " Technical data". VEGACAP 67 • Two-wire...

  • Page 17: Connecting To Power Supply

    Connect the operating voltage according to the following diagrams. Take note of the general installation regulations. As a rule, connect VEGACAP 67 to vessel ground (PA), or in case of plastic vessels, to the next ground potential. On the side of the instrument housing there is a ground terminal between the cable entries.

  • Page 18: Wiring Plan, Single Chamber Housing

    The electrical connection is finished. Wiring plan, single chamber housing Housing overview Fig. 9: Material versions, single chamber housing Plastic (not with dust-Ex) Aluminium Stainless steel Filter element for pressure compensation or blind plug with version IP66/ IP68, 1 bar VEGACAP 67 • Two-wire...
  • Page 19 "Ex-technical data" are available in the "Safety information". The wiring example is applicable for all suitable controllers. Take note of the operating instructions manual of the controller. Suit- able controllers are listed in chapter "Technical data". Fig. 11: Wiring plan Voltage supply VEGACAP 67 • Two-wire...

  • Page 20: Wiring Plan - Version Ip66/Ip68, 1 Bar

    After connecting to voltage supply or after a voltage recurrence, the instrument passes a certain switch on routine. By lowering the current value when switching on, the instrument can output briefly a fault message. I/mA 20,5 < 2,3 Fig. 13: Warm-up reaction Measured value VEGACAP 67 • Two-wire...

  • Page 21: Setup

    Note: As a rule, always set the mode with the mode switch of the signal conditioning instrument before starting setup VEGACAP 67. The switching output will change if you set the mode switch afterwards. This could possibly trigger other connected instruments or devices.
  • Page 22 Measuring range selec- tion switch (1) selection switch (1) on VEGACAP 67 you can change the sensitivity of the probe to the electrical properties of the product and the condi- tions in the vessel. This is necessary so that the level switch can also reliably detect products e.g. with very low or very high dielectric figure.

  • Page 23: Maintenance And Fault Rectification

    24 hour service hotline Should these measures not be successful, please call in urgent cases the VEGA service hotline under the phone no. +49 1805 858550. The hotline is manned 7 days a week round-the-clock. Since we offer this service worldwide, the support is only available in the English language. The service is free, only standard call charges are incurred.
  • Page 24 Shielding Measuring probe Ground potential Reaction after fault recti- Depending on the reason for the fault and the measures taken, the fication steps described in chapter " Set up" may have to be carried out again. VEGACAP 67 • Two-wire...

  • Page 25: Exchange Of The Electronics Module

    9. Insert the electronics module carefully. Make sure that the plug is in the correct position. 10. Screw in and tighten the two holding screws with a screwdriver (Torx size T10 or Phillips 4) 11. Insert the wire ends into the open terminals according to the wir- ing plan VEGACAP 67 • Two-wire...

  • Page 26: Shortening Of The Probe

    Fig. 19: Compensation key Measuring range selection switch (compensation key) Control lamp 3. Keep the measuring range selection switch (1) pushed until the control lamp (2) flashes green. 4. Hence the probe is compensated to the modified length. 5. Carry out the adjustment again. See chapter "Set-up, adjustment elements". VEGACAP 67 • Two-wire...

  • Page 27: How To Proceed If A Repair Is Necessary

    Clean the instrument and pack it damage-proof • Attach the completed form and, if need be, also a safety data sheet outside on the packaging • Please contact the agency serving you to get the address for the return shipment. You can find the agency on our home page www.vega.com. VEGACAP 67 • Two-wire...

  • Page 28: Dismount

    Pass the instrument directly on to a specialised recycling company and do not use the municipal collecting points. If you have no way to dispose of the old instrument properly, please contact us concerning return and disposal. VEGACAP 67 • Two-wire...

  • Page 29: Supplement

    Ʋ Pipe thread, conical (ASME B1.20.1) 1½ NPT Ʋ Flanges DIN from DN 40, ASME from 1½" Weight Ʋ Instrument weight (depending on 0.8 … 4 kg (0.18 … 8.82 lbs) process fitting) Cable connected electrically conductive with the gravity weight. VEGACAP 67 • Two-wire...
  • Page 30 < 0.15 %/10 K of the adjusted measuring range Ambient conditions Ambient temperature on the housing -40 … +80 °C (-40 … +176 °F) Storage and transport temperature -40 … +80 °C (-40 … +176 °F) Distance from the process fittings to the set switching point. Distance from the process fittings to the set switching point. VEGACAP 67 • Two-wire...
  • Page 31 1000 m (3280 ft) Ʋ Min. bending radius 25 mm (0.984 in) with 25 °C (77 °F) Ʋ Diameter approx. 8 mm (0.315 in) Ʋ Colour - standard PE Black Ʋ Colour - standard PUR Blue VEGACAP 67 • Two-wire...

  • Page 32: Dimensions

    Altitude above sea level up to 5000 m (16404 ft) Protection class Dimensions The following dimensional drawings represent only an extract of all possible versions. Detailed dimensional drawings can be downloaded at www.vega.com/downloads under " Drawings". VEGACAP 67 • Two-wire...
  • Page 33 ~ 103 mm (5.91") (4.06") ø 77 mm ø 84 mm (3.03") (3.31") M20x1,5 M20x1,5 M20x1,5 Fig. 22: Housing versions with protection rating IP66/IP68 (1 bar) Stainless steel single chamber (precision casting) Aluminium - single chamber VEGACAP 67 • Two-wire...
  • Page 34 (1.58") (0.59") Fig. 23: VEGACAP 67, threaded version G1½ (ISO 228 T1) and 1½ NPT, -50 … +300 °C (-58 … +572 °F) Version -50 … +400 °C (-58 … +752 °F) only with external housing. See supplementary instructions manual "External housing - VEGACAP, VEGACAL"...

  • Page 35: Industrial Property Rights

    Les lignes de produits VEGA sont globalement protégées par des droits de propriété intellec- tuelle. Pour plus d'informations, on pourra se référer au site www.vega.com. VEGA lineas de productos están protegidas por los derechos en el campo de la propiedad indus- trial. Para mayor información revise la pagina web www.vega.com.
  • Page 36 Subject to change without prior notice © VEGA Grieshaber KG, Schiltach/Germany 2020 VEGA Grieshaber KG Phone +49 7836 50-0 Am Hohenstein 113...
