６－２．Connecting Signal I/O Connector（Ｊ１）
(1) Crimp the contact to the cable used for wiring.
(2) Insert the contact into the housing.
Make sure that the housing No. and the connector No. on the main frame are
matched before inserting the contacts.
(3) Connect the housing to the connector on the main frame.
● The contacts for J1 are 12 pieces.
● When inserting, keep pushing J1 housing into the connector until it is locked.
Also, check if the contacts are not displaced from the housing.
● In wiring, isolate the J1 signal lines from equipment that may be
a source of noise, the power line and the motor line.
Housing for J1
User
controller
CWP
CWP
CCWP
CCWP
+COM
M.F
P.O
R.GND
O.H.A
R.GND
+COM
C.S
●
Use a signal cable of AWG26(0.15mm
The following items are required:
● Housing for J1 (51103-1200:Molex):
● Contact for J1 (50351-8100:Molex):
● Manually operated crimping tool
for AWG28-22(57295-5000:Molex):
(Surface on which the contacts are inserted)
〈Crimping〉
〈Wiring〉 〈Insertion〉
Contact
2
) or more in diameter.
〈Connection〉
Housing
J1
CW+
1 1
CW-
2 2
CCW+
3 3
CCW-
4 4
M.F+
5 5
M.F-
6 6
P.O
7 7
R.GND
8 8
O.H.A
9 9
R.GND
10 10
C.S+
11 11
C.S-
12 12
-24-
Instructions Manual
One unit (accessory)
12 contacts (accessories)
One unit
GD-5510-01
Drive pulse input
Drive pulse input
Motor excitation
stop input
Phase signal output
Overheat alarm
signal output
Step angle
switch input
GD-5510-01
