４－６．Setting HOLD SWITCHING TIME SELECT switch
(1) Set the DHT SEL switch [DHT2][DHT1] to the DRIVE/HOLD CURRENT automatic
switching time required.
DHT2
DHT1
HOLD SWITCHING TIME
４－７．Setting ROTATE CHARACTERISTIC SELECT switch
● By setting the RC SEL switch to [RC1:ON] the vibration of the motor in
acceleration or deceleration may reduce.
● Select it after evaluated characteristic with an actual device.
DRIVE/HOLD CURRENT automatic switching time is set up
with the DHT SEL switch.
The switch is factory-set to [DHT2:OFF][DHT1:OFF](150ms).
OFF
OFF
ON
OFF
ON
OFF
150ms
16ms
8ms
The switch is factory-set to [RC1:OFF].
-19-
Instructions Manual
ON
ON
4ms
GD-5510-01
