OPC UA ACCESS:

By Pressing the
"OPC UA
Access" button from the main window for SW67B39 (Fig. 2) the window "OPC UA Server Access" appears (Fig. 4).
This section is used to define the list of OPC UA variables to read/write.
Figure 4: "OPC UA Server Access" window
The means of the checkboxes inside the table are:
If the field "Enable" is checked, the OPC UA variable is enabled;
In the field "Type" the data format of the OPC UA variable is defined;
In the field "Position" the starting byte of the internal memory arrays where getting the value is defined;
In the field "Length" the byte length of the OPC UA variable is defined;
In the field "Name" the name of the OPC UA variable is defined;
In the field "R/W" the access type of the OPC UA variable is defined;
In the field "Mnemonic" a description of the OPC UA variable is defined.
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual OPC UA Server / EtherNet/IP Slave
Document code: MN67B39_ENG
INFO:
www.adfweb.com
Revision 1.000
Page 17 of 27
