Summary of Contents for Schertler UNICO X
- Page 1 UNICO X • U S E R • M A N U A L C O M B O A M P F O R A C O U S T I C I N S T R U M E N T S V1 EN W W W .
- Page 2 ACOUSTIC X AMPS...
- Page 3 INTRODUCTION Thank you for choosing the UNICO X amplifier. UNICO X represents the state of the art in Swiss amplifier design, reflecting all the needs of the user. Offering a significantly improved power amp and speaker section, together with a crossover filter network, limiter and gain, this impressive 5-channel combo amp provides 280 W (123 dB SPL) of bi-amplified analog power.
-
Page 4: Important Safety Information
IMPORTANT SAFETY INFORMATION SAFETY FIRST! Safety is of major importance when operating any electrical equipment, so please note the following: On a product, a lightning flash within a triangle indicates the presence of uninsulated “dangerous voltage” within the product enclosure. This may be of sufficient magnitude to cause risk of electric shock. -
Page 5: Operational Safety
SCHERTLER technical assistance center. (For more information, you can contact us at the address on the last page of this manual.) - Page 6 1.6. WARM: When active, this low-pass filter dampens higher frequencies to produce a warmer sound when using bridge-mounted pickups such as the SCHERTLER STAT Series for violin, cello and double bass.
- Page 7 INSTRUMENT IN Ø GAIN WARM PARAMETRIC MIDS HIGH REV / AUX VOLUME AUX OUT DECAY REVERB MASTER master 700 Hz gain 2.10 2 .11 3.3 KHz MIC IN INSTRUMENT IN GAIN RESON HIGH REV / AUX VOLUME 240 Hz 150 Hz INSERT LINE OUT D.I.
- Page 8 3.3 KHz MIC IN INSTRUMENT IN GAIN RESON HIGH REV / AUX VOLUME 240 Hz 150 Hz INSERT LINE OUT D.I. OUT flat PARAMETRIC MIDS MIC IN GAIN HIGH REV / AUX VOLUME STEREO IN VOLUME 700 Hz gain 3.3 KHz SWISS MADE 3.1.
- Page 9 6.7. LOW CUT: When active, this filter cuts all frequencies below 180 Hz - ideal if you play an instrument that generates aggressive low frequencies. It enables you to connect a subwoofer, and prevent unwanted vibration and possible damage to your UNICO X. 6.8. MASTER: Controls the overall system volume.
- Page 10 ACOUSTIC X AMPS...
-
Page 11: Mains Power Connection
UNICO X S E R I A L N UM B E R 2 8 0 W A T T A C O U S T I C A C O U S T I C A M P L I F I E R... -
Page 12: Signal Flow
SIGNAL FLOW ACOUSTIC X AMPS... -
Page 13: Technical Information
TECHNICAL INFORMATION Weight 16.8 kg Dimensions (LxDxH) 34.2 x 32.6 x 43.8 cm Frequency Response (@ +/-3 dB) 40 Hz to 20 kHz Sensitivity (1W/1m) @1 kHz 98 dB Power 280 W pure analog power amp SPL Max 123 dB Speakers 1”... - Page 14 Does the I/O INSERT allow you to put effects Yes, the INSERT connection works on the on all channels? Master, so it affects all the channels. Can I use UNICO X with a bass? UNICO X’s Class-A electronics and bootstrap technology inputs...
- Page 15 Will my condenser mic work with the UNICO UNICO X provides way more than the nominal X’s 24 V phantom power? 24 VDC but, since it is not actually 48 VDC we cannot legally label it P48.
-
Page 16: Warranty
COPYRIGHT This manual is the property of SCHERTLER SA and, as such, is subject to Swiss copyright law. No part of this manual should be reproduced, edited or distributed without prior consent from SCHERTLER.
