- Page 1 JAM 100 Combo amplifier for acoustic instruments...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL, WITHIN AN EQUILATERAL TRIANGLE, IS INTENDED TO ALERT THE USER TO THE PRESENCE OF UNINSULATED “DANGEROUS VOLTAGE” WITHIN THE PRODUCT ENCLOSURE THAT MAY BE OF A SUFFICIENT MAGNITUDE TO CONSITUTE A RISK OF ELECTRIC SHOCK TO PERSONS. - Page 3 WARNINGS PRECAUTIONS WARNINGS Please read this manual carefully before using your amplifier and observe all safety precautions Keep this manual for future reference Do not pour any liquids onto this device, or operate it in excessively humid conditions. Do not use or install this device near sources of excessive heat. Do not expose it to direct sunlight, or position it in a dusty environment without any form of protection.
- Page 4 INTRODUCTION An ideal amp for any musical situation. The 100W compact JAM 100 is equipped with a 1” dome tweeter and 6” woofer offering a good, honest sound quality. 3 independent channels plus a CD input (Phono connection) enable the simultaneous connection of several instruments.
- Page 5 1. CHANNELS 1.1. MIC IN (ch. 1 - 2) This input is electronically balanced for XLR type connections (microphones) with 1 Kohm impedance, alternatively to High Z input 1.2. LINE IN (ch. 1 -2) Unbalanced line input for jack type connections (microphone or instruments) with 10 Kohm impedance, alterantively to Mic In input.
- Page 6 2. MASTER 2.1. DIRECT OUT General output. XLR balanced type connector for connections of external systems. The output volume depends on the regulation of the MASTER-VOL. 2.2. REC OUT L/R This unbalanced RCA plugs enable the connection of external systems such as recorders. The output volume can be regulated with the REC OUT control and does not depend on the regulation of the MASTER- VOL.
-
Page 7: Technical Specs
TECHNICAL SPECS Frequency response ........60 Hz - 20 kHz Sensitivity (1W-1m) ........89 dB SPL max ............. 108 dB Woofer ............6” Horn ............Dome 1” Crossover ........... Active 24 dB/octave Box .............. Bass reflex Construction ..........Birch laminated System –... - Page 8 “COMMON SENSE” AND THUS, MISUSE OF OUR PRODUCTS ARE NOT COVERED UNDER RIGHTS OBTAINED THROUGH OUR WARRANTY POLICY OR THAT OF INTERNATIONALLY RECOGNIZED TERMS AND CONDITIONS. SCHERTLER SA IS CONSTANTLY AIMING TO IMPROVE ITS RANGE OF PRODUCTS THEREFORE, SCHERTLER SA RESERVES THE RIGHT TO AMEND PRODUCT SPECIFICATIONS WITHOUT NOTICE.
